SideWaffle: How to create your own VS template pack

If you haven’t heard I’m working on a project with Mads Kristensen called SideWaffle. SideWaffle is a Visual Studio Extension which contains many different Visual Studio Item and Project Templates. This is a community effort and all open source at https://github.com/ligershark/template-builder. You can create your own Item Templates and Project Templates and send a Pull Request for them to be included in the main repo. Check out the video below for more info on SideWaffle.

SideWaffle intro video

Item Templates are used by VS developers to create files using the Add New Item dialog. SideWaffle already contains a number of Item Templates such as; Angular Controller, robots.txt, SignalR Hub and Client, etc. For more info on how to create Item Templates with SideWaffle watch the 4 minute video below.



Project Templates are the items that show up in the Add New Project dialog. They provide a starting point for developers creating new projects. SideWaffle already has a few project templates as well, such as a Google Chrome Extension. You can learn more about how to create Project Templates in this video.



Now that we’ve gotten the intro out of the way, let’s explore how you can create your own SideWaffle.

How to create your own SideWaffle

The idea behind SideWaffle is that we will have a shared VS extension for popular VS Item and Project Templates. Instead of contributing to the main SideWaffle project you may be interested in creating your own distribution that does not have the standard templates. For example, I’ve heard from both the Orchard and Umbraco that they are interested in creating template packs for their communities. It wouldn’t make much sense to include those templates in the main SideWaffle project. Instead it would be best to create a separate distribution for each; OrchardWaffle and UmbracoWaffle.

So how can you do this? It’s pretty easy actually. SideWaffle is built on top of a NuGet package, TemplateBuilder, which is also open source at https://github.com/ligershark/template-builder. All the core functionality of SideWaffle is contained in that NuGet package. To create your own SideWaffle follow these steps:

After you add the TemplateBuilder NuGet package a few things happen:

  1. The build process of the project is modified to support building Item and Project templates
  2. Your .vsixmanifest file is updated with two new Asset tags
  3. An ItemTemplates folder is created with a sample Item Template

From here on you can build the project and after installing the generated .vsix you can have users easily create instances of your item or project templates.

You can add additional Item Templates, as well as create Project Templates in your project. That’s pretty much all there is to getting started with your own Waffle pack.

Let me know if you have any issues or comments.

Happy Waffleing!



Sayed Ibrahim Hashimi | http://msbuildbook.com | @SayedIHashimi

extensibility | SideWaffle | Visual Studio | Visual Studio 2012 | VSIX Friday, October 11, 2013 5:11:26 PM (GMT Daylight Time, UTC+01:00)  #     |
Saturday, September 21, 2013

How to extend the web publish process without modifying project contents

When automating web publishing for Visual Studio projects in many cases your first step will be to create a publish profile for the project in VS. There are many cases in which you cannot, or would not like to do this. In this post I’ll show you how you can take an existing project and use an MSBuild file to drive the publish process. In that I’ll also show how you can extend the publish process without modifying either the project or any of its contents.

Before we get too far into this, if you are not familiar with how to publish your VS web projects from the command line you can read our docs at ttp://www.asp.net/mvc/tutorials/deployment/visual-studio-web-deployment/command-line-deployment.

When you publish a project from the command line using a publish profile you typically use the syntax below.

msbuild .\MyProject.csproj /p:VisualStudioVersion=11.0 /p:DeployOnBuild=true /p:PublishProfile=<profile-name-or-path>

In this snippet we are passing in a handful of properties. VisualStudioVersion dictates which version of MSBuild targets are used during the build. See http://sedodream.com/2012/08/19/VisualStudioProjectCompatabilityAndVisualStudioVersion.aspx for more details on that. DeployOnBuild=true injects the publish process at the end of build. PublishProfile can either be the name of a publish profile which the project contains or it can be the full path to a publish profile. We will use PublishProfile with that second option, the full path.

So we need to pass in the full path to a publish profile, which typically is a .pubxml file. A publish profile is just an MSBuild file. When you pass in PublishProfile and DeployOnBuild=true, then the publish profile is Imported into the build/publish process. It will supply the publish properties needed to perform the publish.

Let’s see how that works. I have a sample project, MySite, which does not have any publish profiles created for it. I have created a publish profile, ToFileSys.pubxml, in another folder that will be used though. The contents of that file are below.

ToFileSys.pubxml

<Project ToolsVersion="4.0" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
  <PropertyGroup>
    <WebPublishMethod>FileSystem</WebPublishMethod>
    <ExcludeApp_Data>False</ExcludeApp_Data>
    <publishUrl>C:\temp\Publish\01</publishUrl>
    <DeleteExistingFiles>False</DeleteExistingFiles>
  </PropertyGroup>
</Project>

This publish profile will publish to a local folder. I just created this file in VS with a different project and then just copied it to the folder that I needed, and removed properties which are only used for the inside of VS experience. We can publish the MySite project using this profile with the command below.

msbuild MySite.csproj
            /p:VisualStudioVersion=11.0
            /p:DeployOnBuild=true
            /p:PublishProfile=C:\data\my-code\publish-samples\publish-injection\build\ToFileSys.pubxml

When you execute this the file specified in PublishProfile will be included into the build process.

Taking it up a level

steps

Now let’s see how we can take this to the next level by having a single script that will be used to publish more than one project using this technique.

In the sample files (which you can find links for at the end of the post). I have a solution with two web projects, MySite and MyOtherSite. Neither of these projects have any publish profiles created. I have created a script which will build/publish these projects which you can find at build\publish.proj in the samples. The contents of the file are shown below.

publish.proj

<?xml version="1.0" encoding="utf-8"?>
<Project ToolsVersion="12.0" xmlns="http://schemas.microsoft.com/developer/msbuild/2003" DefaultTargets="BuildProjects">
  <!--
  This file is used in two ways.
    1. Drive the build and publish process
    2. It is used by the publish process during the build of MySite to configure/extend publish
        Note: 1. Is kicked off by the use on the cmd line/build server. 2. Is invoked by this script itself.
              This file is injected into the publish process via the PublishProfile property.
  -->
  <PropertyGroup>
    <VisualStudioVersion Condition=" '$(VisualStudioVersion)'=='' ">11.0</VisualStudioVersion>
    <Configuration Condition=" '$(Configuration)'=='' ">Release</Configuration>
    <!-- Location for build output of the project -->
    <OutputRoot Condition=" '$(OutputRoot)'=='' ">$(MSBuildThisFileDirectory)..\BuildOutput\</OutputRoot>
    <!-- Root for the publish output -->
    <PublishFolder Condition=" '$(PublishFolder)'==''">C:\temp\Publish\Output\</PublishFolder>
  </PropertyGroup>

  <ItemGroup>
    <ProjectsToBuild Include="$(MSBuildThisFileDirectory)..\MySite\MySite.csproj">
      <AdditionalProperties>
        VisualStudioVersion=$(VisualStudioVersion);
        Configuration=$(Configuration);
        OutputPath=$(OutputRoot);
        WebPublishMethod=FileSystem;
        publishUrl=$(PublishFolder)MySite\;
        DeployOnBuild=true;
        DeployTarget=WebPublish;
        PublishProfile=$(MSBuildThisFileFullPath)
      </AdditionalProperties>
    </ProjectsToBuild>

    <ProjectsToBuild Include="$(MSBuildThisFileDirectory)..\MyOtherSite\MyOtherSite.csproj">
      <AdditionalProperties>
        VisualStudioVersion=$(VisualStudioVersion);
        Configuration=$(Configuration);
        OutputPath=$(OutputRoot);
        WebPublishMethod=FileSystem;
        publishUrl=$(PublishFolder)MyOtherSite\;
        DeployOnBuild=true;
        DeployTarget=WebPublish;
        PublishProfile=$(MSBuildThisFileFullPath)
      </AdditionalProperties>
    </ProjectsToBuild>
  </ItemGroup>

  <Target Name="BuildProjects">
    <MSBuild Projects="@(ProjectsToBuild)" />
  </Target>

  <!-- ***************************************************************************************
 The targets below will be called during the publish process.
 These targets are injected into the publish process for each web project.
 These targets will not have access to any new values for properties/items from
 the targets above this.
 *************************************************************************************** -->

  <Target Name="AfterWebPublish" AfterTargets="WebPublish">
    <Message Text="Inside AfterWebPublish" Importance="high"/>
  </Target>

</Project>

This file is pretty simple, it declares some properties which will be used for the build/publish process. Then it declares the projects to be built with an item list named ProjectsToBuild. When declaring ProjectsToBuild I use the AdditionalProperties metadata to specify MSBuild properties to be used during the build process for each project. Let’s take a closer look at those properties.

<AdditionalProperties>
  VisualStudioVersion=$(VisualStudioVersion);
  Configuration=$(Configuration);
  OutputPath=$(OutputRoot);
  WebPublishMethod=FileSystem;
  publishUrl=$(PublishFolder)MySite\;
  DeployOnBuild=true;
  DeployTarget=WebPublish;
  PublishProfile=$(MSBuildThisFileFullPath)
</AdditionalProperties>

I’ll explain all the properties now. VisualStudioVersion, Configuration and OutputPath are all used for the build process. The other properties are related to publishing. If you want to publish from the file system those properties (WebPublishMethod, publishUrl, DeployOnBuild, and DeployTarget) must be set. The most important property there is PublishProfile.

PublishProfile is set to $(MSBuildThisFileFullPath) which is the full path to publish.proj. This will instruct the build process of that project to import publish.proj when its build/publish process is started. It’s important to note that a “new instance” of the file will be imported. What that means is that the imported version of publish.proj won’t have access to any dynamic properties/items created in publish.proj.

The reason why PublishProfile is specified there is so that we can extend the publish process from within publish.proj itself. publish.proj has a target, AfterWebPublish, which will be executed after each project is executed. Let’s see how this works.

We can execute the publish process with the command below.

msbuild .\build\publish.proj /p:VisualStudioVersion=11.0

After executing this command the tail end of the result is shown in the image below.


In the image above you can see that the MyOtherSite project is being publish to the specified location in publish.proj and the AfterWebPublish target is executed as well.



In this post we’ve seen how we can use an MSBuild file as a publish profile, and how to extend the publish process using that same file.

You can download the samples at https://dl.dropboxusercontent.com/u/40134810/blog/publish-injection.zip. You can find the latest version in my publish-samples repository at publish-injection.

Sayed Ibrahim Hashimi | http://msbuildbook.com | @SayedIHashimi

msbuild | Visual Studio | Visual Studio 2012 | web | Web Publishing Pipeline Saturday, September 21, 2013 7:57:03 PM (GMT Daylight Time, UTC+01:00)  #     |
Saturday, June 08, 2013

Introducing VsixCompress–a NuGet package to compress your Visual Studio Package

A few weeks ago I blogged about a Visual Studio extension, Farticus, which I’m working on with Mads Kristensen. In that post I described how the default compression of a .vsix (the artifact that is created for a Visual Studio Package) is not as small as it could be. It’s better to get a fully compressed VSIX because when users install the component the download time can be significantly reduced. In that post I described how you could use the Zip task from the MSBuild Extension Pack to have a fully compressed .vsix file. I will now show you how I’ve simplified this.

Icon for package VsixCompressVsixCompress

Since my previous post I’ve created a NuGet package, VsixCompress which simplifies this greatly. If you have an existing Visual Studio package and want to have a fully compressed .vsix file then all you need to do is install the VsixCompress package.




After you install this package the following happens.

  1. NuGet package is downloaded and installed to the packages folder
  2. The project is edited to include an import for a new .targets file
  3. The build process is extended to compress the .vsix file automatically

After installing this package once you build the generated .vsix is much smaller than before. In the default case where you select to create a new C# VS Package the created .vsix is 17kb. After adding VsixCompress the resulting .vsix is only 9kb. That’s almost half the size. That’s all you need to know for local development. If you have a build server setup then there are a couple of additional steps. Let’s go over those now.

Build Server Support

I have blogged before about issues of shipping build updates in NuGet. To briefly summarize, when leveraging NuGet Package Restore you have to be careful if any of those NuGet packages have build updates. When using Package Restore the NuGet packages which contain the imported .targets file(s) are restored after the build starts. What this means is that the .targets files will never be imported (or an old copy is imported in the case the file exists from a previous build). The only way to work around this is to restore the packages before the .sln/.csproj file themselves are built. You can read the full details at http://sedodream.com/2012/12/24/SlowCheetahBuildServerSupportUpdated.aspx. I have a NuGet package, PackageRestore, which can help here. Take a look at my previous post How to simplify shipping build updates in a NuGet package. Now that we’ve discussed all the details that you need let’s discuss what my plans are going forward with this.

Plans going forward

I’m hoping to add the following features over the course of the next few weeks.

FYI VsixCompress is open source so you can take a look at the code, or better yet contribute at https://github.com/sayedihashimi/vsix-compress.

Please let me know what you think of this!

Sayed Ibrahim Hashimi | http://msbuildbook.com | @SayedIHashimi

extensibility | Visual Studio | VSIX Saturday, June 08, 2013 1:42:57 AM (GMT Daylight Time, UTC+01:00)  #     |
Saturday, June 01, 2013

Hijacking the Visual Studio Build Process

Have you ever wanted to use Visual Studio to manage project artifacts but wanted to have a fully custom build process? The recommend way to do this is to build a Custom Visual Studio Project System, but there is a much easier way for lightweight needs. In this post I’ll show you how to take an existing project and “replace” the build process used? For example, wouldn’t it be cool if you could develop a Chrome Extension with VS? When you do a build it would be great to generate the .zip file to for the Chrome Gallery in the output folder. Doing this is way easier than you might think.

Before I go over the steps to do this let me explain the “contract” between Visual Studio and MSBuild. The primary interactions around build in Visual Studio include the following actions in VS. Including what VS does when the action is invoked.

For more details you can read Visual Studio Integration (MSBuild). The easiest way to completely customize the VS build process is to do the following:

  1. Create the correct project based on the artifacts you plan on using (i.e. if you’re going to be editing .js files then create a web project)
  2. Edit the project file to not import any of the .targets files
  3. Define the following targets; Build, Rebuild and Clean

After that when you invoke the actions inside of VS the correct action will be executed in your project.

Let’s look at a concrete example. I’ve been working on a Chrome extension with Mads Kristensen the past few days. The entire project is available on github at https://github.com/ligershark/BestPracticesChromeExtension. When it came time to try out the extension or to publish it to the Chrome store we’d have to manually create it, which was annoying. We were using a standard web project to begin with. Here is how we made the workflow simple. Edited the project file to disable the Import statements. See below.

<Import Project="$(MSBuildBinPath)\Microsoft.CSharp.targets"
    Condition="false" />
<Import Project="$(VSToolsPath)\WebApplications\Microsoft.WebApplication.targets"
    Condition="false and '$(VSToolsPath)' != ''" />
<Import Project="$(MSBuildExtensionsPath32)\Microsoft\VisualStudio\v10.0\WebApplications\Microsoft.WebApplication.targets"
    Condition="false" />

For each of these targets I added/updated the condition to ensure that the .targets file would never be loaded. The reason why I did not simply remove these is because in some cases VS may get confused and try to “upgrade” the project and re-insert the Import statements.

After that I added the following statements to the .csproj file.

  <PropertyGroup>
    <LigerShareChromeTargetsPath>$(BuildFolder)\ligersharek.chrome.targets</LigerShareChromeTargetsPath>
  </PropertyGroup>
  <Import Project="$(LigerShareChromeTargetsPath)" Condition="Exists($(LigerShareChromeTargetsPath))" />

Here I defined a new property to point to a custom .targets file and a corresponding Import statement. Now let’s take a look at the ligershark.chrome.targets file in its entirety.

<?xml version="1.0" encoding="utf-8"?>
<Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
  <PropertyGroup>
    <UseHostCompilerIfAvailable>false</UseHostCompilerIfAvailable>
  </PropertyGroup>
  <ItemDefinitionGroup>
    <AppFileNameItem>
      <Visible>false</Visible>
    </AppFileNameItem>
    <AppFolderItem>
      <Visible>false</Visible>
    </AppFolderItem>
  </ItemDefinitionGroup>

  <UsingTask AssemblyFile="$(BuildLib)MSBuild.ExtensionPack.dll" TaskName="MSBuild.ExtensionPack.Compression.Zip" />

  <Target Name="Build">
    <MakeDir Directories="$(OutputPath)" />

    <ItemGroup>
      <_AppCandidateFilesToZip Remove="@(_AppCandidateFilesToZip)" />
      <_AppCandidateFilesToZip Include="@(Content);@(None)" />
    </ItemGroup>

    <FindUnderPath Path="$(AppFolder)" Files="@(_AppCandidateFilesToZip)">
      <Output TaskParameter="InPath" ItemName="_AppFilesToZip" />
    </FindUnderPath>
    <Message Text="App files to zip: @(_AppFilesToZip->'%(RelativeDir)%(Filename)%(Extension)')" />

    <PropertyGroup>
      <_AppFolderFullPath>%(AppFolderItem.FullPath)</_AppFolderFullPath>
    </PropertyGroup>

    <Message Text="Creating package .zip at [%(AppFileNameItem.FullPath)]" Importance="high" />
    <MSBuild.ExtensionPack.Compression.Zip
      TaskAction="Create"
      CompressFiles="@(_AppFilesToZip)"
      ZipFileName="%(AppFileNameItem.FullPath)"
      RemoveRoot="$(_AppFolderFullPath)"
      CompressionLevel="BestCompression" />
  </Target>

  <PropertyGroup>
    <RebuildDependsOn>
      Clean;
      Build;
    </RebuildDependsOn>
  </PropertyGroup>
  <Target Name="Rebuild" DependsOnTargets="$(RebuildDependsOn)" />
  <Target Name="Clean">
    <!-- delete all the files in the output folder -->
    <ItemGroup>
      <_FilesToDelete Remove="@(_FilesToDelete)" />
      <_FilesToDelete Include="$(OutputPath)**\*" />
    </ItemGroup>
    <Message Text="Deleting files: @(_FilesToDelete)" />
    <Delete Files="@(_FilesToDelete)" />
  </Target>
</Project>

As you can see I defined the following targets; Build, Rebuild, and Clean. This is what we discussed earlier as the requirements. Now when I click the Build button in VS a .zip file containing the Chrome Extension is created in the bin\ folder. Additionally no other step (i.e. any typical build step) is performed here. The only thing happening is what is defined in the Build target here. Similarly when I Rebuild or Clean the Rebuild or Clean target is invoked respectively. This is  a pretty neat way to modify an existing project to completely replace the build process to suit your needs.

There are a few things in the .targets file that I’d like to point out.

UseHostCompilerIfAvailable

In the .targets file I have set the property declaration <UseHostCompilerIfAvailable>false</UseHostCompilerIfAvailable>. When you are working with a project in Visual Studio there is a compiler, the host compiler, that Visual Studio has which can be used. For performance reasons in most cases this compiler is used. In this case since we do not want any standard build actions to be executed this performance trick is undesired. You can easily disable this by setting this property to false.

After this MSBuild will always be invoked when performing any build related action.

Visible metadata for Item Lists

When using MSBuild you typically represent files as values within an item list. One issue that you may encounter when modifying a project which will be loaded in VS is that the files inside of those item lists will show up in Visual Studio. If you want to disable this for a particular value in an item list you can add the well known metadata <Visible>false</Visible>. For example you could have the following.

<ItemGroup>
    <IntermediateFile Include="cache.temp">
        <Visible>false</Visible>
    </IntermediateFile>
</ItemGroup>

If you don’t want to add this to every value in the item list then you can set the default value using an ItemDefinitionGroup.  For example take a look at the elements below.

<ItemDefinitionGroup>
  <AppFileNameItem>
    <Visible>false</Visible>
  </AppFileNameItem>
  <AppFolderItem>
    <Visible>false</Visible>
  </AppFolderItem>
</ItemDefinitionGroup>

After this declaration is processed if the Visible metadata is accessed for AppFileNameItem or AppFolderItem on a value which does not declare Visible, then false is returned.



The rest of the content of the .targets file is pretty straightforward. This post shows a basic example of how you can take an existing Visual Studio project and completely replace the build process.



This project is open source at https://github.com/ligershark/BestPracticesChromeExtension.



Sayed Ibrahim Hashimi | http://msbuildbook.com | @SayedIHashimi

msbuild | MSBuild 4.0 | Visual Studio | Visual Studio 2012 Saturday, June 01, 2013 6:47:16 PM (GMT Daylight Time, UTC+01:00)  #     |
Saturday, October 27, 2012

MSBuild: how to set the configuration property

When you are building a .sln file or a .csproj/.vbproj/etc you need to be careful how you set the Configuration property. Once this property is set you do not want to change the value of it. Because of this it is best to specify this as a global property. To do that you can pass it in on the command line. If you are using the MSBuild task then you can pass it in via Properties or AdditionalProperties. What you do not want to do is to set this value inside your .csproj/.vbproj or any imported file. The only time when this is OK if there is a condition which will not set the property if it’s already been set. This is exactly how the default .csproj/.vbproj files are authored:

<Configuration Condition=" '$(Configuration)' == '' ">Debug</Configuration>

If you do set this property w/o the conditional not to overwrite an existing value you may experience really strange behavior during your builds. And it may be difficult to diagnose the issue as well.

Now let me explain why you cannot do this. When you build a .csproj/.vbproj MSBuild will start creating an in-memory representation of the entire project. It will start with the .csproj/.vbproj file itself. It will read the file from top to bottom. When a property is encountered it is evaluated. If a property is encountered that relies on another one, for example

<IntermediateOutputPath Condition=" '$(PlatformName)' == 'AnyCPU' ">$(BaseIntermediateOutputPath)$(Configuration)\</IntermediateOutputPath>

The properties inside the expression will be evaluated on whatever values exist for the properties at the time. In this case ItermediateOutputPath will be the value of BaseIntermediateOutputPath and Configuration.

If a property is encountered which specifies a value for a property which has been previously declared, the previous value will be discarded.

The implications of this are subtle but very simple; once a property has been set which has dependent properties you must not overwrite that property. This is because when a dependent property is encountered it is evaluated immediately. You cannot re-evaluate that property. So if you set a property during your build, some existing dependent properties which were evaluated before the value change will continue to use the old value. There is no way to re-evaluate those properties.

Now lets see how this relates to the Configuration property specifically.

The contents of the .csproj/.vbproj are properties/items along with an import to Microsoft.csharp.targets (Microsoft.VisualBasic.targets for .vbproj) which then imports Microsoft.Common.targets. If you look in Microsoft.common.targets you will see many different properties which are declared using $(Configuration). So this means that you must treat the Configuration property with care and abide by the rule that I have outlined above.

FYI If you want more details on this I have explained this entire process in great detail in my book Inside MSBuild and Team Build.

Configuration for web publishing

If you have used the new web publish experience in Visual Studio 2012 (also available for VS2010 from the Azure SDK) you may have noticed that the web publish profiles are MSBuild files. They are stored under Properties\PublishProfiles (My Project\PublishProfiles for VB) and have extensions of .pubxml. In that file (or in a .pubxml.user file associated with it) you will find a property defined as

<LastUsedBuildConfiguration>Release</LastUsedBulidConfiguration>

This value corresponds to the value for the Configuration drop down in the VS web publish dialog. When you kick off a publish in VS we use this value and kick off a build and specify Configuration as a global property which is passed in. The reason why we did not name this property Configuration is because the web publish profile is imported into the web project itself during the publish process. By the file being imported you can natively access all the properties/items of the .csproj/.vbproj and also easily extend the build process. Since that is the case we cannot set the Configuration property because we know it’s value has already been set. Due to this when publishing from the command line you must specify the Configuration property.

Sayed Ibrahim Hashimi | @SayedIHashimi

msbuild | MSDeploy | Visual Studio | Visual Studio 2008 | Visual Studio 2010 Saturday, October 27, 2012 3:49:02 AM (GMT Daylight Time, UTC+01:00)  #     |
Monday, August 20, 2012

Web Deploy (MSDeploy) how to sync a folder

Today I saw the following question on StackOverflow MSDeploy - Deploying Contents of a Folder to a Remote IIS Server and decided to write this post to answer the question.

Web Deploy (aka MSDeploy) uses a provider model and there are a good number of providers available out of the box. To give you an example of some of the providers; when syncing an IIS web application you will use iisApp, for an MSDeploy package you will use package, for a web server webServer, etc. If you want to sync a local folder to a remote IIS path then you can use the contentPath provider. You can also use this provider to sync a folder from one website to another website.

The general idea of what we want to do in this case is to sync a folder from your PC to your IIS website. Calls to msdeploy.exe can be a bit verbose so let’s construct the command one step at at time. We will use the template below.

msdeploy.exe -verb:sync -source:contentPath="" -dest:contentPath=""

We use the sync verb to describe what we are trying to do, and then use the contentPath provider for both the source and the dest. Now let’s fill in what those values should be. For the source value you will need to pass in the full path to the folder that you want to sync. In my case the files are at C:\temp\files-to-pub. For the dest value you will give the path to the folder as an IIS path. In my case the website that I’m syncing to is named sayedupdemo so the IIS path that I want to sync is ‘sayedupdemo/files-to-pub’. Now that give us.

msdeploy.exe –verb:sync -source:contentPath="C:\temp\files-to-pub" -dest:contentPath='sayedupdemo/files-to-pub'

For the dest value we have not given any parameters indicating what server those command are supposed to be sent to. We will need to add those parameters. The parameters which typically need to be passed in are.

In my case I’m publishing to a Windows Azure Web Site. So the values that I will use are:

All of these values can be found in the .publishSettings file (can be downloaded from Web Site dashboard from WindowsAzure.com). For the ComputerName value you will need to append the name of your site to get the full URL. In the example above I manually added ?site=sayedupdemo, this is the same name as shown in the Azure portal. So now the command which we have is.

msdeploy.exe
    –verb:sync
    -source:contentPath="C:\temp\files-to-pub"
    -dest:contentPath='sayedupdemo/files-to-pub'
            ,ComputerName="https://waws-prod-blu-001.publish.azurewebsites.windows.net/msdeploy.axd?site=sayedupdemo"
            ,UserName='$sayedupdemo'
            ,Password='thisIsNotMyRealPassword'
            ,AuthType='Basic'

OK we are almost there! In my case I want to make sure that I do not delete any files from the server during this process. So I will also add –enableRule:DoNotDeleteRule. So our command is now.

msdeploy.exe
    –verb:sync
    -source:contentPath="C:\temp\files-to-pub"
    -dest:contentPath='sayedupdemo/files-to-pub'
            ,ComputerName="https://waws-prod-blu-001.publish.azurewebsites.windows.net/msdeploy.axd?site=sayedupdemo"
            ,UserName='$sayedupdemo'
            ,Password='thisIsNotMyRealPassword'
            ,AuthType='Basic'
    -enableRule:DoNotDeleteRule

At this point before I execute this command I’ll first execute it passing –whatif. This will give me a summary of what operations will be without actually causing any changes. When I do this the result is shown in the image below.

SNAGHTML204f5cd

After I verified that the changes are all intentional, I removed the –whatif and executed the command. After that the local files were published to the remote server. Now that I have synced the files each publish after this will be result in only changed files being published.

If you want to learn how to snyc an individual file you can see my previous blog post How to take your web app offline during publishing.

dest:auto

In the case of the question it was asked with dest:auto, you can use that but you will have to pass in the IIS app name as a parameter and it will replace the path to the folder. Below is the command.

msdeploy.exe
    -verb:sync
    -source:contentPath="C:\temp\files-to-pub"
    -dest:auto
        ,ComputerName="https://waws-prod-blu-001.publish.azurewebsites.windows.net/msdeploy.axd?site=sayedupdemo"
        ,UserName='$sayedupdemo'
        ,Password='thisIsNotMyRealPassword'
        ,AuthType='Basic'
-enableRule:DoNotDeleteRule
-setParam:value='sayedupdemo',kind=ProviderPath,scope=contentPath,match='^C:\\temp\\files-to-pub$'

Thanks,
Sayed Ibrahim Hashimi @SayedIHashimi

MSDeploy | Visual Studio | web | Web Deployment Tool Monday, August 20, 2012 4:08:11 AM (GMT Daylight Time, UTC+01:00)  #     |
Sunday, August 19, 2012

Profile specific web.config transforms and transform preview

When we released VS2010 we add support for web.config (XDT) transforms during publish/package. Note: From now on I’ll only use the word publish from now on but the full content relates to packaging as well. In the original implementation when you published your web project the web.config file would be transformed by the file web.{Configuration}.config, where {Configuration} is the project build configuration. For example Debug, or Release. If you publish on Release and there exists a web.release.config we will take your web.config and transform it with web.release.config before publishing.

Cascading web.config transformations

In VS 2012 (as well as the publishing updates for VS2010 through the Azure SDK) now support the concept of publish specific transforms. You can also now specify the project configuration used for a profile when publishing on the publish dialog.

SNAGHTML45b19fc

In this case I have created a profile named Production and set the Configuration to Release. When I publish this project the following transformations will be applied (if the files exist) in this order.

  1. web.release.config
  2. web.production.config

I think that we got this wrong when we initially implemented the support. We should have created profile specific transforms instead of ones based on build config, but having these cascading transforms are still pretty useful. For example I may want to remove the attribute debug=”true” from the compilation element and then inside of the profile specific transform we would override appSettings/WCF endpoints/logging config/etc for that environment.

In VS there is a right-click option on web.config for Add Config Transform, but we were not able to update the functionality of that to automatically create profile specific transforms. Don’t worry it will be released soon with our first set of updates for web tooling. For now you will need to create a new file with the correct name and add it to your project. Note: if you want it to show up nested under web.config you’ll need to add the metadata <DependentUpon>Web.config</DependentUpon> to the item in the .csproj/.vbproj file.

web.config transform preview

Previously the only way to test the functionality for these transformation was to actually publish or package the web project. This gets old pretty quick. In order to simplify creating these transforms we have introduced the Preview Transform menu option. This is the coolest feature in VS 2012 (OK I’m a bit biased, but still its the coolest).


In my web.release.config I have left the default contents, which just removes the debug attribute. Here is what I see when I select this on web.release.config for my project.


You can see that in the image above we can see that the debug flag was indeed removed as expected.

In my web.production.config I have a transform which simply updates the email app setting value. Here is the really cool part when I preview the transform for web.production.config the previewer will look into the profile and determine the build configuration which has been configured, and it will ensure that transform is applied before the profile specific one. For example take a look at the result for web.production.config.


In the image above you can see the note that web.release.config was applied first followed by web.production.config. In the result we can see that web.release.config removed the debug flag and that web.production.config updated the email address value.

We also do a little bit to help out in case there are errors in either the web.config or a transform. You can see errors in the Output Window and double click it to go directly to where the error exists.

Note: Scott Hanselman has a 5 minute video showing this and other updates.

Another note: If you need to transform any file besides web.config during publish then install my extension SlowCheetah.

Sayed Ibrahim Hashimi | @SayedIHashimi

Config-Transformation | msbuild | Visual Studio | Visual Studio 2012 Sunday, August 19, 2012 11:18:16 PM (GMT Daylight Time, UTC+01:00)  #     |

Visual Studio project compatability and VisualStudioVersion

One of the most requested features of Visual Studio 2012 was the ability to open projects in both VS 2012 as well as VS 2010 (requires VS 2010 SP1). In case you haven’t heard we did implement that feature. You may be wondering how we were able to do this and how this may impact you.

If you open the .csproj/.vbproj for a Web Project created in VS2010 you will see the following import statement.

<Import Project="$(MSBuildExtensionsPath32)\Microsoft\VisualStudio\
v10.0\WebApplications\Microsoft.WebApplication.targets" />

When you open this project in VS 2012 there are a few changes made to your project file to ensure that it can be opened in both VS 2010 SP1 and VS 2012. One of the changes made to the project when it is first loaded in VS 2012 is to add the following to replace that import statement.

<PropertyGroup>
  <VisualStudioVersion Condition="'$(VisualStudioVersion)' == ''">10.0</VisualStudioVersion>
  <VSToolsPath Condition="'$(VSToolsPath)' == ''">
    $(MSBuildExtensionsPath32)\Microsoft\VisualStudio\v$(VisualStudioVersion)</VSToolsPath>
</PropertyGroup>
<Import Project="$(VSToolsPath)\WebApplications\Microsoft.WebApplication.targets" Condition="'$(VSToolsPath)' != ''" />

We removed the hard-coded 10.0 and instead used the property VisualStudioVersion. When building in Visual Studio 2012 this value will always be 11.0, but for VS 2010 it doesn’t exist. That is why we defaulted it to 10.0 above.

There are some scenarios where building from the command line will require to set this property explicitly. Before we get there let me explain how this property gets set (in this order)

  1. If VisualStudioVersion is defined as an environment variable/global MSBuild property, that is used.
    • This is how VS and the VS developer command prompt set this value
  2. Based on the file format version of the .sln file (toolset used is sln file format –1)
    • To simplify this statement, the .sln file will build with specifying VisualStudioVersion to the value of the version of VS which created the .sln file.
  3. Choose default
    • 10.0 if VS 2010 is installed
    • Highest-versioned sub-toolset version installed

For #2 when you are building a .sln file the value of VisulStudioVersion will be –1 of the Format Version found in the .sln file. The important thing to note here is that if you build a .sln file it will build with the value of VisulStudioVersion corresponding to the version of VS which created the .sln file. So if you create a .sln file in VS2012 and you always build that .sln file the value for VisualStudioVersion will be 11.0. In many cases if you build the .sln file you are good.

If you are building .csproj/.vbproj files w/o going through a .sln file? If you build a web project from the command line (not the developer prompt) then the value for VisualStudioVersion used will be 10.0. That is an artifact of the properties which I showed above. In this case you should pass this in as an MSBuild property. For example

msbuild.exe MyAwesomeWeb.csproj /p:VisualStudioVersion=11.0

In this case I’m passing in the property explicitly. This will always override any other mechanism to determine the value for VisualStudioVersion. If you are using the MSBuild task in a build script, then you can specify the property either in the Properties attribute or the AdditionalProperties attribute. See my previous blog post on the difference between Properties and AdditionalProperties.

If you encounter any funny behavior when building/publishing and you notice that the wrong .targets files are being imported then you may need to specify this property.

Sayed Ibrahim Hashimi | @SayedIHashimi

msbuild | Visual Studio | Visual Studio 11 | Visual Studio 2010 | Visual Studio 2012 | web | Web Publishing Pipeline Sunday, August 19, 2012 10:06:56 PM (GMT Daylight Time, UTC+01:00)  #     |
Thursday, August 16, 2012

SlowCheetah v2.4 Released

I jus released a new version of SlowCheetah, my Visual Studio extension which enables you to transform app.config, and other XML files, during F5 for non-web projects. In this update I added support for Visual Studio 2012 as well as the bug fixes below.
  1. Fix for Preview command doesn't show up for all web.config transforms
  2. Fix for XML transforms not working with Azure SDK
  3. Fix for XML transforms not working with Azure SDK
  4. Fix for .config files do no transform in VS 2012 RC
  5. Fix for In web project, project File gets modified while adding transformation
  6. Fix for Add Transform should not show up for .settings files
  7. Fix for Transforms should be added as None

If you are interested in the project you can take a look at the code at https://github.com/sayedihashimi/slow-cheetah and if you have any issues please file a bug at https://github.com/sayedihashimi/slow-cheetah/issues.



Thanks,
Sayed Ibrahim Hashimi | @SayedIHashimi

    SlowCheetah | Visual Studio | Visual Studio 11 | Visual Studio 2010 | Visual Studio 2012 Thursday, August 16, 2012 1:54:26 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, August 09, 2012

    How to create Web Deploy packages in Visual Studio 2012

    When building Visual Studio 2012 we made an effort to reduce the amount of menu options which are shown on toolbars as well as context menus. If you have used any of the pre-release versions of VS 2012 then you might have noticed that the Build Deployment Package and Package/Publish Settings context menu options are gone from Web Application Project.

    In VS2010 when creating a Web Deploy package the publish dialog was not used because there were no relevant settings. Now that we have enabled features like integration to enable Entity Framework Code First migrations, incremental database updates (coming in the final release), connection string updates, etc. we needed to find a way that you could leverage these great features when creating Web Deploy packages. The solution that we decided to go with was to have first class support for creating packages directly from the publish dialog.

    After that, we felt that it would be better to have a single way to create a package than two different ways with pros and cons. And we would benefit by being able to simplify our context menu. To create a package for your Web Application Project in VS 2012 (or in VS 2010 if you have the Azure SDK 1.7+) you can follow the steps below.

    1. Right click on your project and select Publish
    2. Create a new profile for your Web Deploy package
    3. Specify the path where the package should go (must end with a .zip)
    4. Click Publish

    After the initial create for the profile, creating additional packages is even easier. You just right click on your project select Publish and then click the Publish button.

    The reason why we remove the context menu for the Package/Publish Settings is that most of the package and publish related settings are on the publish dialog. The existing settings from VS 2010 are still available on the property pages if you need to get to them.

    One other change which we made was to hide the One Click toolbar. This is a toolbar which can be used to publish your web project in one click after the web publish profile has been created. After looking at the number of times that the button was used we determined that it did not meet the bar to be shown by default. Don’t worry if that was your favorite button (I know it was mine), you can bring it back quickly. The easiest way to turn it on is to press CTRL + Q (to bring up the quick launch), type in ‘one click’ and then click on the single result. That should show the One Click toolbar.

    FYI if you want to learn more we have a great walk through on publishing a web project with an EF Code First model at Deploying an ASP.NET Web Application to a Windows Azure Web Site and SQL Database.

    If you have any questions feel free to email me at sayedha@microsoft.com.

    Sayed Ibrahim Hashimi | @SayedIHashimi

    Visual Studio | Visual Studio 11 | Visual Studio 2012 | Web Publishing Pipeline Thursday, August 09, 2012 10:39:46 PM (GMT Daylight Time, UTC+01:00)  #     |
    Monday, August 06, 2012

    Plans regarding Website projects and Web Deployment Projects

    The release of Visual Studio 2012 is right around the corner. If you’ve been following our blog/twitter then you may know that many of the Web related components of Visual Studio are now“out-of-band”, meaning that we can update them independently of Visual Studio itself. Because of this we are planning to ship updates a few times a year. We are currently in the process for planning our first update for VS 2012 and we wanted to share some of the items that we are planning to work on. We would like to get your feedback on these ideas to ensure that we are doing the right things. If you have comments please do let us know. FYI the updates that I describe below will be made available for both VS 2012 as well as VS 2010.

    Website Project Updates

    When you use Visual Studio there are two types of web projects you can create: a Web Application Project (WAP, this includes MVC) and a Website Project (WSP). In VS 2012 we did a lot of work to update the publish experience for WAPs. When we set out for these updates we planned to take these enhancements and make the available to Website projects as well. As we progressed it became evident that we did not have the resources to implement the features for both WAP and WSP in time for VS 2012. So we focused on creating the right experience for WAPs and we also added an extensibility point into WSP which will allow us to replace the existing publish dialog. The reason why we focused on WAP first was because WAPs already have support for Web Deploy (MSDeploy) based publishing as well as a formal build/publish process captured in MSBuild. WSP does not have either of these so it would have taken more time to start with WSP.

    When VS 2012 is released the publish experience for WSP will be the same which was available in VS2010 but we will have a release a few months after the release which will bring all the publish goodness to Website Projects! This will include all the features which are available to Web Application Projects including; the ability to publish using.

    Since both project systems will be using the exact same code whenever we add a feature it will immediately be available to both. In today’s world they are two entirely different code bases (the WSP publishing experience is currently native code where as the WAP publish dialog is managed). This will allow us to maintain a consistent publish experience and also enable us to deliver features more quickly.

    Since WSP does not have a “build” process you might be wondering how we are planning to hook this all together since our entire publish pipeline is captured in MSBuild. Here is a rough idea of what we are currently thinking. After you use the new publish dialog to create a publish profile for the first time we will do a number of things:

    1. Create a new folder to contain needed artifacts
      1. The folder may be in the root of the Website project, but we are considering placing it somewhere outside as well
      2. The name of this folder is not yet finalized, but it could be something like _Publish or _Project
    2. Create an MSBuild file for the Website in that folder, this will capture information like; included files, references, properties to control publish process
      1. The primary purpose of dropping this file is to facilitate command line publish scenarios, without this we could publish from Visual Studio but not from the command line
      2. When you make changes in Visual Studio like adding a reference we will automatically keep this file up to date
    3. Create the publish profile in that folder (this is a .pubxml file)
    4. When the site is being published the working directory (i.e. obj\ folder) will be outside the root of the website, most likely in the same folder which contains the WSP root

    After we have those things in place for the most part the publish dialog will be able to treat both projects in the same way. These files will by default be stored in version control and can be shared with other team members. Sensitive information such as the MSDeploy password will be stored in another file and encrypted per-user/per-machine in a .user file which is not checked in.

    Web Deployment Projects

    A few months after Visual Studio 2005 shipped we released the first version of Web Deployment Projects, and we updated WDP for both VS 2008 and VS 2010 and released them a few months after each of those releases as well. WDPs are used for a few different scenarios including the following.

    1. Publishing a Website project using MSDeploy
    2. Command line publish support
    3. Customizing the publish process for a WAP
    4. Running ASP.NET precompile/merge for a WSP or WAP

    When we looked at the scenarios that WDPs are typically used for and then compared that to features which we have for WAP and WSP (after the updates mentioned above) we noticed that most (if not all) scenarios where WDP is used can be covered without requiring a WDP. Our new publish experience already has first class support for MSDeploy, command line publishing, and for extensibility so that covers #1-#3. Regarding #4 for WAPs we have already added ASP.NET precompile/merge as a publish option (you can find it in the Package/Publish Web tab). Since WSP does not have any property pages we are likely to move that option to being on the publish dialog itself or we will expose those options in another way for WSP. We have not yet settled on that design.

    It may not seem like it but updating WDP to support VS2012 is a significant effort. Knowing that, and that most of the scenarios where WDP are used can now be transitioned to the new experience, we have decided to invest in giving WSP projects first class publishing support instead of updating VS 2012 to support WDP. We think that this is the right decision because we are unifying the publish experience for both project systems and it allows us to create a deeper set of features going forward instead of investing in different things and wasting effort. If you have a scenario that you think we have missed please do not hesitate to reach out to me by email at sayedha@microsoft.com and let me know.


    Sayed Ibrahim Hashimi | @SayedIHashimi

    asp.net | MSDeploy | Visual Studio | Visual Studio 2010 | Visual Studio 2012 | Web Publishing Pipeline Monday, August 06, 2012 10:16:47 PM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, July 12, 2012

    Visual Studio 2012 RC Web Tooling Extensions update

    If you have been following our blog and twitter accounts then you most likely have heard that some of the Web components of Visual Studio 2012 are now “Out of Band”. What that means is that we can update those components separately from Visual Studio itself. Because of this we will be posting updates on a regular basis. Today marks the first of these updates, and its targeting Visual Studio 2012 RC. In this post I will describe how to get the update and then what the update contains.

    How to get the update

    If you already have Visual Studio 2012 RC installed when you launch VS you will see a notification in the task tray like the image below.


    Note: VS checks for updates once a day so if you don’t see this notification today its likely that the check has already been performed

    After you click on the notification you will be brought to the Extension and Updates dialog. To get the web updates you should go to the Visual Studio Gallery tab and then click Update on the Web Tooling Extensions item.


    After installing the update you will need to restart VS.

    What is contained in the update

    The goals that we had when creating this update mainly consisted of.

    1. Fix key customer reported bugs which we didn’t have time to complete for the RC release
    2. Test out the update mechanism publicly

    Since the intent of this release was not to light up any new features you won’t find any new functionality, but you may discover that an issue you are running into has been fixed. Most of the bugs which we fixed were filed by customer on Microsoft Connect, though some came in through other channels. For the Connect bugs you will see a link to the bug details, for Connect bugs filed as private there will not be a link. Below you will find a list of the fixed bugs as well as a brief description of the bug.

    Web publishing raises an exception due to <connectionStrings> content

    If the root web.config contained elements under <connectionStrings> that did not have a name attribute an exception was raised.

    Reported Bugs



    Web publish to the File system doesn’t always include all files

    When publishing a web project to the file system there are cases where files are not getting updated on publish.

    Reported Bugs

    Web publish doesn’t handle read-only profiles correctly

    In certain cases if a web publish profile is read-only it can cause VS to crash.

    Reported Bugs

    Web publish doesn’t include all files if there is no project configuration matching the solution configuration

    The drop down for Configuration on the publish dialog was mapped to Solution Configurations instead of Project Configurations. Because of this if a Solution Configuration was selected which did not have a corresponding Project Configuration the files would not be published. We have updated the dialog to show the correct value.

    Reported Bugs

    Wrap up

    We are really excited to be able to publish updates on a more regular basis and we hope that you will find that helpful as well. In case you guys were wondering if we listen to feedback/Connect bugs I hope that this post helps to show that we are listening to feedback and working to resolve bugs which get filed on Connect. Keep filing the bugs so that we can make our product even better. If you have already filed bugs on Connect then Thank You!


    Sayed Ibrahim Hashimi | @SayedIHashimi

    Visual Studio | Visual Studio 2012 | Web Development | Web Publishing Pipeline Thursday, July 12, 2012 8:01:03 PM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, June 15, 2012

    Downloading the Visual Studio Web Publish Updates

    I have written a few posts recently describing out updated web publish experience. These new experience is available for both Visual Studio 2010 as well as Visual Studio 2012 RC. You can use the links below to download these updates in the Azure SDK download. Below are links for both versions.

    The Web Publish experience is chained into VS 2012 RC so if you have installed VS 2012 RC with the Web features then you already have these features.

    Thanks,
    Sayed Ibrahim Hashimi @SayedIHashimi

    asp.net | Deployment | Visual Studio | Visual Studio 11 | Visual Studio 2010 | web | Web Deployment Tool | Web Publishing Pipeline Friday, June 15, 2012 8:30:40 PM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, June 07, 2012

    ASP.NET providers and SQL Azure

    We have two sets of ASP.NET providers which currently exist; the ASP.NET SQL providers, and the ASP.NET Universal Providers. In VS 2010 the SQL providers were in only providers used for our project templates. In VS 2012 we have switched to using the Universal Providers. One of the drawbacks of the SQL providers is that it leverages DB objects of SQL server which are not available in SQL Azure.

    In our updated web publish experience we have an Update Database checkbox which can be used to incrementally publish the database to the destination database. In this case if the source connection string is used by the ASP.NET SQL providers and you are publishing to SQL Azure then you will see the following message on the dialog.

    SNAGHTML48cbb8

    Note: you may see the Update Database checkbox disabled, please visit http://sedodream.com/2012/06/07/VSPublishDialogUpdateDatabaseDialogDisabled.aspx for more info on why.

    The publish dialog is letting you know that the SQL providers are not compatible with SQL Azure and helps you convert to using the Universal Providers. After you install the Universal Providers the web.config entry will be commented out and new entries will be inserted for the Universal Providers. Your existing database will not be impacted, we’ll create a new connection string pointing to a new database. If you had any data in the SQL Providers database you will have to re-create those objects in the new database.

    If you have any questions please feel free to directly reach out to me at sayedha(at){MicrosoftDOTCom}.

    Sayed Ibrahim Hashimi @SayedIHashimi

    Visual Studio | Visual Studio 11 | Visual Studio 2010 | web | Web Publishing Pipeline Thursday, June 07, 2012 11:41:46 PM (GMT Daylight Time, UTC+01:00)  #     |

    Database settings in the VS Publish dialog

    In Visual Studio 2010 we introduced a database publishing experience in the Package/Publish SQL (PP/SQL) properties page. This support relies on generating create scripts from the source database and then executing those scripts when you publish your web application. For more details regarding this feature take a look at Package/Publish SQL Tab, Project Properties. One of the negative aspects of the implementation that we have there is that the DB schema publishing is not incremental, it always executes create scripts. So in many cases you publish your app for the first time and things are great, but the next time you try to publish you receive errors because it tries to create DB objects which already exist.

    In our improved publish dialog we have a new database publishing experience which is incremental, so you don’t run into the same issues when re-deploying your database. All of the configuration for this is within the publish dialog itself. If you have a project which already has DB publish settings on the Package/Publish SQL tab (under any build configuration/platform) then you will see the message shown in the image below.

    SNAGHTML2bb135

    The new incremental DB schema publish mechanism is not compatibly with the feature set on the PP/SQL tab. For each web publish profile you can either use the settings on the PP/SQL tab or you can opt-in to the new experience on the publish dialog. We implemented it this way in order to introduce the new feature set and to ensure that existing publish scenarios are not broken.

    FYI there is a related post on why the Update database checkbox is disabled in the publish dialog which you may be interested in.

    If you have any questions please feel free to directly reach out to me at sayedha(at){MicrosoftDOTCom}.

    Sayed Ibrahim Hashimi @SayedIHashimi

    Microsoft | Visual Studio | Visual Studio 2010 | Web Publishing Pipeline Thursday, June 07, 2012 11:09:13 PM (GMT Daylight Time, UTC+01:00)  #     |

    VS Publish dialog Update Database dialog disabled

    If you have tried out our new Web Publish experience in Visual Studio you may have noticed that the Update Database checkbox is disabled. See the image below.


    The intended behavior of this checkbox is to enable you to incrementally publish your database schema from the source (the connection string in web.config) to the destination (whatever connection string is in the text box). The difference between an incremental publish and a typical publish is that for incremental publishes only changes are transferred from source to destination. With a full publish the first time that you publish your DB schema everything is created, and the next time that you try to publish you will receive an error because it tries to re-create existing DB objects.

    The functionality of the Update database checkbox leverages an MSDeploy provider. We were hoping to complete that provider and give it to hosters in time for the release but we were unable to do so. We are working on completing the provider and partnering with hosters to install these in time for the launch of Visual Studio 2012 RTM.

    In the mean time if you need to publish your DB schema you can use the Package/Publish SQL tab (caution: the DB publishing here is not incremental). If you are going to use the PP/Sql tab to publish to SQL Azure then there are some special consideraions that you will need to take. You can learn more about those by visiting http://msdn.microsoft.com/en-us/library/dd465343.aspx and searching for “Azure” on that page.

    If you have any questions please feel free to directly reach out to me at sayedha(at){MicrosoftDOTCom}.


    Thanks,
    Sayed Ibrahim Hashimi @SayedIHashimi

    Visual Studio | Visual Studio 11 | Visual Studio 2010 | web | Web Development | Web Publishing Pipeline Thursday, June 07, 2012 10:44:26 PM (GMT Daylight Time, UTC+01:00)  #     |
    Monday, May 14, 2012

    MSBuild how to execute a target after CoreCompile

    I was on StackOverflow today and noticed a question along these lines “How to I create a target which is executed when CoreCompile is, and that is skipped when CoreCompile is skipped?” Below is my answer.

    This is a tricky problem to solve for the general case, but it is pretty easy in your case because CoreCompile has special built in support for this scenario. Before I go into the details of how you can accomplish this with CoreCompile let me explain how it works in general.

    Explanation of the general case

    In MSBuild targets are skipped due to Incremental Building. Incremental Build is driven purely off of the Inputs and Outputs attributes on the Target itself. The inputs are a list of files that the target will "use" and the outputs are a list of files that are "generated" by the target. I'm using quotes because its a loose concept not a concrete one. To simplify it you can just treat inputs/outputs as lists of files. When the target is about to be executed MSBuild will take the inputs and compare the timestamps of them to the outputs. If all the outputs are newer then the inputs then the target will be skipped. (FYI If you want to know what happens when only some outputs are out-of-date read my blog athttp://sedodream.com/2010/09/23/MSBuildYouveHeardOfIncrementalBuildingButHaveYouHeardOfPartialBuilding.aspx).

    In any case if you want a target to be skipped you have to craft your Inputs/Outputs correctly. In your case you want to skip your target whenever the CoreCompile is skipped, so at the surface it would seem that you could simply copy the Inputs/Outputs of CoreCompile but that doesn't work. It doesn't work because when CoreCompile is executed the files may be out-of-date but that target itself brings them up-to-date. Then when you target is executed since they are all up-to-date it will be skipped. You would have to copy the Inputs/Outputs and append an additional file to inputs/outputs which you target creates. This would ensure that your target wouldn't get skipped during that first pass.

    Specific solution for CoreCompile

    If you take a look at the project file you will see towards the bottom that the file Microsoft.Common.targets is Imported, this file will then import the language specific .targets file. For example it will Import either Microsoft.CSharp.targets or Microsoft.VisualBasic.targets (if you are using C# or VB). In those .targets files you will find CoreCompile defined. In the definition for CoreCompile you will find the following at the end.

    <CallTarget Targets="$(TargetsTriggeredByCompilation)" Condition="'$(TargetsTriggeredByCompilation)' != ''"/>

    This will call all the targets defined in the TargetsTriggeredByCompilation property. So if you want your target to be called whenever CoreCompile is executed you can extend that property. Here is how to do that.

    <PropertyGroup>
      <TargetsTriggeredByCompilation>
        $(TargetsTriggeredByCompilation);
        MyCustomTarget
      </TargetsTriggeredByCompilation>
    </PropertyGroup>

    <Target Name="MyCustomTarget">
      <Message Text="MyCustomTarget called" Importance ="high"/>
    </Target>

    In this case I define the property TargetsTriggeredByCompilation and I append MyCustomTarget to it. It's very important that you include the $(TargetsTriggeredByCompilation); there, if you don't then you won't be appending but overwriting. So if anyone else used this technique you'd wipe out their target.

    Below is an image showing where I build once and CoreCompile and MyCustomTarget are executed. Then the second build CoreCompile is skipped any MyCustomTarget is never called.

    build-output



    Sayed Ibrahim Hashimi @SayedIHashimi

    msbuild | Visual Studio Monday, May 14, 2012 4:14:13 AM (GMT Daylight Time, UTC+01:00)  #     |
    Sunday, May 13, 2012

    VS Web Publish: How to parameterize connection strings outside of web.config

    If you have used the Visual Studio web publish in either VS 2010 or VS 11 to create Web Deploy packages then you probably know that we parameterize connection strings in web.config automatically. In case you are not familiar with Web Deploy parameters, they are a way to declare that you want to easily be able to update a value of something when publishing the package later on. Connection strings are good examples of something which typically needs to be updated during publish.

    As I previously stated if you create a Web Deploy package in Visual Studio we will automatically create Web Deploy parameters for all your connection strings in web.config. Earlier today I saw a question on StackOverflow asking how to parameterize connection strings in non-web.config files (question actually asked something else, but I think this is what he’s really wanting). I created a sample showing how to do this. Below is what the connectionStrings element looks like in web.config.

    <connectionStrings configSource="connectionStrings.config" />

    And here is connectionStrings.config

    <?xml version="1.0" encoding="utf-8" ?>
    <connectionStrings>
      <clear/>
      <add name="ApplicationServices"
               connectionString="data source=.\SQLEXPRESS;Integrated Security=SSPI;AttachDBFilename=|DataDirectory|\aspnetdb.mdf;User Instance=true"
               providerName="System.Data.SqlClient" />
      <add name="OtherConnectionString"
           connectionString="data source=.\SQLExpress;Integrated Security=SSPI;Initial Catalog=foo"
           providerName="System.Data.SqlClient"/>
    </connectionStrings>

    In order to parameterize these connection strings you will have to extend the Web Publish Pipeline. To do that create a file named {project-name}.wpp.targets in the root of the project in which you are working (for VS 11 projects you can place all this directly inside of the .pubxml files). This will be an MSBuild file which will get imported into the build/publish process. Below is the file which needs to be created.

    <?xml version="1.0" encoding="utf-8"?>
    <Project ToolsVersion="4.0" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <ItemGroup>
        <!-- Here we need to declare MSDeploy parameters for connection strings in connectionStrings.config -->
        <MsDeployDeclareParameters Include="ApplicationServices-ConnectionString" >
          <Kind>XmlFile</Kind>
          <Scope>connectionStrings.config$</Scope>
          <Match>/connectionStrings/add[@name='ApplicationServices']/@connectionString</Match>
          <Description>Connection string for ApplicationServices</Description>
          <DefaultValue>data source=(localhost);Initial Catalog=AppServices</DefaultValue>
          <Tags>SqlConnectionString</Tags>
        </MsDeployDeclareParameters>

        <MsDeployDeclareParameters Include="OtherConnectionString-ConnectionString" >
          <Kind>XmlFile</Kind>
          <Scope>connectionStrings.config$</Scope>
          <Match>/connectionStrings/add[@name='OtherConnectionString']/@connectionString</Match>
          <Description>Connection string for OtherConnectionString</Description>
          <DefaultValue>data source=(localhost);Initial Catalog=OtherDb</DefaultValue>
          <Tags>SqlConnectionString</Tags>
        </MsDeployDeclareParameters>
      </ItemGroup>

    </Project>

    Here you can see that I am creating values for MSDeployDeclareParameters. When you package/publish this item list is used to create the MSDeploy parameters. Below is an explanation of the metadata values each contain.

    After you create this file you will need to close/re-open VS (it caches imported .targets files). Then you can create a web deploy package. When you do so these new parameters will be declared. In my case I then imported this in the IIS manager and here is the dialog which shows up for the parameters.

    SNAGHTML94cce08

    As you can see the Application Path parameter is shown there as well as my custom connection string values. When I update the values in the text box and opened connectionStrings.config on my web server they were the values I entered in the dialog box.

    FYI I have uploaded this sample to my github account at ParameterizeConStringConfig.

    Sayed Ibrahim Hashimi @SayedIHashimi

    msbuild | MSBuild 4.0 | MSDeploy | Visual Studio | Web Deployment Tool | Web Publishing Pipeline Sunday, May 13, 2012 10:18:03 PM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, March 14, 2012

    Package web updated and video below

    A couple months ago I blogged about a Package-Web which is a NuGet package that extends the web packaging process in Visual Studio to enable you to create a single package which can be published to multiple environments (it captures all of your web.config transforms and has the ability to transform on non-dev machines). Since that release I have updated the project and tonight I created a video which shows the features a bit you can check it out on Youtube. It’s embedded below.

    You can install this via NuGet, the package name is PackageWeb.


    Package-Web is an open source project and you can find it on my github account at https://github.com/sayedihashimi/package-web.

    Thanks,
    Sayed Ibrahim Hashimi @SayedIHashimi

    msbuild | MSDeploy | Visual Studio | web | Web Deployment Tool | Web Development | Web Publishing Pipeline Wednesday, March 14, 2012 6:08:57 AM (GMT Standard Time, UTC+00:00)  #     |
    Monday, December 12, 2011

    SlowCheetah XML transforms from a CI server

    Please read my updated post, the info below is no longer required for some scenarios SlowCheetah build server support updated

    A few months ago I published a Visual Studio add-in, SlowCheetah – XML Transforms, which enables you to transform any XML file during a build in the same way that you can transform the web.config during publish/package for web projects. Since then I’ve received numerous requests to demonstrate how the transforms can be kicked in from a CI server. It’s actually pretty easy because all the logic from a transform perspective is contained inside of MSBuild tasks/targets. The Visual Studio add-in itself is only delivering the support for gestures/preview.

    Before I dive into how to enable this for a CI server let me explain how the plugin works and then the CI integration will be come much clearer. When you load a project/solution in Visual Studio for the first time after you installed SlowCheetah a set of files will be written to %localappdata%\Microsoft\MSBuild\SlowCheetah\v1. Those file are:



    Name

    Description

    Install-Manifest.xml An XML file which describes the files that are installed. This is used by the plugin itself, you should never have to do anything with this file.
    SlowCheetah.Tasks.dll The assembly which contains the MSBuild task which transforms XML files.
    SlowCheetah.Transforms.targets The MSBuild file which enables XML file transformation



    The add-in adds the following menu command to any XML file for supported project types.


    When you click on this for the first time the add-in needs to make some changes to your project file so you are prompted to accept that. After you do the following changes are applied to your project file.

    1. A new MSBuild property SlowCheetahTargets is added to the project and it points to the SlowCheetah.transforms.targets file in %localappdata%
    2. An import for that file is added

    More specifically the elements added to your project file are.

    <PropertyGroup>
      <SlowCheetahTargets Condition=" '$(SlowCheetahTargets)'=='' ">$(LOCALAPPDATA)\Microsoft\MSBuild\SlowCheetah\v1\SlowCheetah.Transforms.targets</SlowCheetahTargets>
    </PropertyGroup>

    <Import Project="$(SlowCheetahTargets)" Condition="Exists('$(SlowCheetahTargets)')" />

    Note: If you look at your project file they will not be next to each other. The property will be towards the top of the project file and the import towards the bottom.

    So now you might have an idea of why this won’t work on your CI server, the file SlowCheetah.Transforms.targets will not exist in the %localappdata% folder. There is an easy to way to fix this which doesn’t require any changes to your CI server. Check in the files and update your import. Here is what I did:

    1. Create a folder named SlowCheetah in the same folder as my solution
    2. Added SlowCheetah.Tasks.dll and SlowCheetah.Transforms.targets to that folder
    3. Create a solution folder named SlowCheetah in the solution
    4. Drag and drop the files from your SlowCheetah folder into the SolutionFolder
    5. Updated my project file to point to these files

    Now your solution should look roughly like the following image.


    Note: Steps #3/#4 are not strictly required

    For #5 you’ll have to edit your project file, don’t worry its an easy modification. Just follow these steps:

    1. Right click on the project and select unload
    2. Right click on the unloaded project and select Edit
    3. Update the value for the SlowCheetahTargets import

    In my case the folder that I placed the files into is 1 directory above the project itself. So the new value for the property is as follows.

    <SlowCheetahTargets>$(MSBuildProjectDirectory)\..\SlowCheetah\SlowCheetah.Transforms.targets</SlowCheetahTargets>

    After that I checked in all the files, kicked off a build and viola the files are transformed. Let me know if you need any more info.

    Sayed Ibrahim Hashimi – @SayedIHashimi

    Note: I work for Microsoft, but these are my own opinions

    msbuild | SlowCheetah | Visual Studio | Visual Studio 2010 Monday, December 12, 2011 5:02:42 AM (GMT Standard Time, UTC+00:00)  #     |
    Saturday, January 08, 2011

    Video on Web Deployment using Visual Studio 2010 and MSDeploy

    Back in November I participated in Virtual Tech Days which is an online conference presented by Microsoft. In the session I discussed the enhancements to web deployment using Visual Studio 2010 and MSDeploy. Some of the topics which I covered includ:

    You can download the video & all of my sample files at http://virtualtechdays.com/pastevents_2010november.aspx. In the samples you will find all of the scripts that I used and a bunch of others which I didn’t have time to cover. Enjoy!

    Sayed Ibrahim Hashimi @sayedihashimi

    Config-Transformation | IIS | msbuild | MSDeploy | speaking | Visual Studio | Visual Studio 2010 | web | Web Deployment Tool | Web Development | Web Publishing Pipeline Saturday, January 08, 2011 8:34:08 PM (GMT Standard Time, UTC+00:00)  #     |
    Friday, July 23, 2010

    Visual Studio Ideas

    Do you have a great idea for the next version of Visual Studio and you want to get your voice heard? Now is your chance! Go to twitter and post a message stating your request with the hash tag #vswish and we will take a look at it. We are listening to that channel so please do submit your feedback.

    Sayed Ibrahim Hashimi

    feature-request | Visual Studio Friday, July 23, 2010 8:24:45 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, June 10, 2010

    Visual Studio file encoding issues:

    Have you ever executed a .cmd file (or .bat) file and received a message that looks like the following at the top of your script (including image for compatibility) image ? This was really annoying to me until I find out what was happening. I noticed that Visual Studio (2010 at least, but I think previous version as well but not sure) was changing the encoding of my .cmd files to be UTF-8! For example consider this simple script (sample.cmd) that I created with Notepad.

    echo 'hello world'

    When I execute this .cmd file from the command line the results are as shown below.


    What I did then was to simply create a copy of that file and placed that in a file named sample-vs.cmd and then edited the script using Visual Studio 2010 to have the contents below.

    echo 'hello world from Visual Studio'

    When I execute that .cmd file to my surprise the results shown below are displayed.


    I was definitely not expecting that (OK yeah I was because I created that script for this blog post, but just go with it). I then opened the file in notepad and it looked normal. So I edited it it notpad, saved it and the result was still the same. The first line was not being processed correctly, it seemed. As I was editing the file I noticed the encoding of the files were different. The encoding for the sample.cmd file was set to ANSI and for sample-vs.cmd UTF-8. See for yourself from the screen shots below.



    So I switched the setting for the sample-vs.cmd file to ANSI, executed the script and all was good!

    I’m not sure why Visual Studio is changing the encoding for these files, but it looks like a bug to me. I have logged a bug with Microsoft at https://connect.microsoft.com/VisualStudio/feedback/details/566322/vs-2010-changs-encoding-of-cmd-file-to-utf-8. The bug may not be visible yet, but hopefully it will become public so that you can vote on it if you have been bitten by this bug.

    Sayed Ibrahim Hashimi

    batch-file | bug | cmd-file | connect | Visual Studio | Visual Studio 2010 Thursday, June 10, 2010 4:24:01 AM (GMT Daylight Time, UTC+01:00)  #     |
    Sunday, May 09, 2010

    Visual Studio: Unable to Edit and Continue?

    The past few days I was unable to Edit and Continue in Visual Studio 2010 Ultimate from my home machine, which is running Windows 7 64bit. I knew there were some issues with this on 64bit, I figured one of my projects was not targeting x86 so I just ignored it. Then today I was really getting annoyed at seeing the dialog.

    edit-and-continue

    So I started playing around with the configuration settings made sure that everything was in order and still no dice.

    After that I performed a repair of Visual Studio, and then reset all the settings under Tools>Import and Export Settings and that still didn’t solve the problem. Then I remembered that I change my IntelliTrace settings the other day so I went to disable it and to my surprise I saw the dialog box shown below.

    edit-and-continue2

    When I changed the IntelliTrace setting to collect call information I didn’t notice the warning stating “Edit and continue is disabled when collecting Call Information”! So I changed the setting and everything was good. Microsoft should add this to the Edit and Continue dialog box not available, I’ll ping a few people I know about that. FYI I created this question on Stackoverflow before I resolved it myself.

    Sayed Ibrahim Hashimi

    Edit and Continue | IntelliTrace | Visual Studio | Visual Studio 2010 Sunday, May 09, 2010 12:19:38 AM (GMT Daylight Time, UTC+01:00)  #     |
    Saturday, May 08, 2010

    Visual Studio projects not building anymore?

    Recently I had the chance to work on a WPF app and it was behaving very strangely when I built and ran the application. For instance I tried to debug the application from Visual Studio and I received an error staging “Visual Studio cannot start debugging because the debug target ‘PATH HERE’ is missing. Please build the project and retry, or set the OutputPath and AssemblyName properties appropriately to point at the correct location for the target assembly.

    vs-build-error-01

    So I checked the properties, every thing looked good. I even built the project from the command line and it built fine. Anywayz at some point after that I was able to debug the app. But then I noticed that the UI was not getting updated with my changes. So I started digging a bit deeper. I noticed that when I ran a Clean from Visual Studio the output files for that particular project.

    I then rebuilt the solution in Visual Studio. From the Output window I selected all the text,copied it, and then pasted that into an editor. After looking at the message

    ------ Skipped Clean: Project: R…ion: Debug Any CPU ------
    Project not selected to build for this solution configuration
    ------ Skipped Clean: Project: R…Admin.Wpf, Configuration: Debug x86 ------
    Project not selected to build for this solution configuration
    ------ Clean started: Project: Test…er, Configuration: Debug Any CPU ------
    Build started 5/8/2010 1:10:02 AM.

    I immediately knew that there was an incorrect value in the build configuration manager. You can find the configuration manager from the toolbar.


    Here is what I found.


    In this dialog there are two project set not to build for Debug builds; the DB project and the Wpf project. The DB project is OK to not build on Debug if there are a small % of DB changes versus code changes. If that is the case the devs can just build the DB project manually when the change it. In the case of the Wpf project, it should be set to build and the fact that it wasn’t was causing all the issues. So I checked the build check box, clicked the Close button and it was all good. You should also make sure that all other configuration as setup correctly. You don’t want to get bitten by this again.

    Sayed Ibrahim Hashimi

    Visual Studio | Visual Studio 2010 | WPF Saturday, May 08, 2010 6:33:26 AM (GMT Daylight Time, UTC+01:00)  #     |
    Saturday, May 01, 2010

    Web Deployment Tool (MSDeploy) : Build Package including extra files or excluding specific files

    If you are using Visual Studio 2010 then you may already be aware that Web Deployment Tool (aka MSDeploy) is integrated into Visual Studio. I’ve posted a few blog entries already about this tool. Two of the common questions that I get discussing this with people are

    1. How do I exclude files from being placed in the package?
    2. How do I add other files to the created package?

    I will address these two questions here, first we look at the easier one, how to exclude files but we will go over a bit of background first.

    Web Publishing Pipeline

    With Visual Studio 2010 a new concept has been created which is known as the Web Publishing Pipeline. In a nutshell this is a process which will take your web application, build it and eventually create a package that you can use to deploy your application. This process is fully captured in MSBuild. With VS 2010 many targets and many tasks are shipped to support this process. Since its captured in MSBuild format, you can customize and extend to your hearts desire. So what we need to do is hook into this process to perform the customizations that we need. This process is captured in the following files.

    %program files%\MSBuild\Microsoft\VisualStudio\v10.0\WebApplications\Microsoft.WebApplication.targets
    %program files%\MSBuild\Microsoft\VisualStudio\v10.0\Web\Microsoft.Web.Publishing.targets

    The Microsoft.WebApplication.targets file is imported by the web applications projects file, then that file imports the Microsoft.Web.Publishing.targets file.

    Excluding files from being packaged

    If you open the project file of a web application created with VS 2010 towards the bottom of it you will find a line with.

    <Import Project="$(MSBuildExtensionsPath32)\Microsoft\VisualStudio\v10.0\WebApplications\Microsoft.WebApplication.targets" />

    BTW you can open the project file inside of VS. Right click on the project pick Unload Project. Then right click on the unloaded project and select Edit Project.

    This statement will include all the targets and tasks that we need. Most of our customizations should be after that import, if you are not sure put if after! So if you have files to exclude there is an item name, ExcludeFromPackageFiles, that can be used to do so. For example let’s say that you have file named Sample.Debug.js which included in your web application but you want that file to be excluded from the created packages. You can place the snippet below after that import statement.

    <ItemGroup>
      <ExcludeFromPackageFiles Include="Sample.Debug.xml">
        <FromTarget>Project</FromTarget>
      </ExcludeFromPackageFiles>
    </ItemGroup>

    By declaring populating this item the files will automatically be excluded. Note the usage of the FromTarget metadata here. I will not get into that here, but you should know to always specify that.

    Including extra files into the package

    Including extra files into the package is a bit harder but still no bigee if you are comfortable with MSBuild, and if you are not then read this.  In order to do this we need to hook into the part of the process that collects the files for packaging. The target we need to extend is called CopyAllFilesToSingleFolder. This target has a dependency property, PipelinePreDeployCopyAllFilesToOneFolderDependsOn, that we can tap into and inject our own target. So we will create a target named CustomCollectFiles and inject that into the process. We achieve this with the following (remember after the import statement).

    <PropertyGroup>
      <CopyAllFilesToSingleFolderForPackageDependsOn>
        CustomCollectFiles;
        $(CopyAllFilesToSingleFolderForPackageDependsOn);
      </CopyAllFilesToSingleFolderForPackageDependsOn>
    </PropertyGroup>

    This will add our target to the process, now we need to define the target itself. Let’s assume that you have a folder named Extra Files that sits 1 level above your web project. You want to include all of those files. Here is the CustomCollectFiles target and we discuss after that.

    <Target Name="CustomCollectFiles">
      <ItemGroup>
        <_CustomFiles Include="..\Extra Files\**\*" />

        <FilesForPackagingFromProject  Include="%(_CustomFiles.Identity)">
          <DestinationRelativePath>Extra Files\%(RecursiveDir)%(Filename)%(Extension)</DestinationRelativePath>
        </FilesForPackagingFromProject>
      </ItemGroup>
    </Target>

    Here what I did was create the item _CustomFiles and in the Include attribute told it to pick up all the files in that folder and any folder underneath it. Then I use this item to populate the FilesForPackagingFromProject item. This is the item that MSDeploy actually uses to add extra files. Also notice that I declared the metadata DestinationRelativePath value. This will determine the relative path that it will be placed in the package. I used the statement Extra Files%(RecursiveDir)%(Filename)%(Extension) here. What that is saying is to place it in the same relative location in the package as it is under the Extra Files folder.

    Admittedly this could be easier, but its not too bad, and its pretty flexible.

    Sayed Ibrahim Hashimi

    msbuild | MSBuild 4.0 | MSDeploy | Visual Studio | Visual Studio 2010 | Web Deployment Tool | Web Publishing Pipeline Saturday, May 01, 2010 4:09:16 AM (GMT Daylight Time, UTC+01:00)  #     |
    Monday, April 26, 2010

    Config transformations outside of web app builds

    If you are using Visual Studio 2010 then you may already be familiar with the Web.config transformations that are now available. What you might not know is that you can use that same technology to transform config files outside of the build process. You will need Visual Studio 2010 installed on the machine where you perform these transformations. It is very easy to perform these transformation as well. Let’s say that we start with the app.config file shown below.

    <configuration>
        <connectionStrings>
            <clear/>
            <add name="Default" connectionString="Data Source=localhost;Initial Catalog=Sample01;Integrated Security=True;" />
        </connectionStrings>

        <appSettings>
            <add key="contactEmail" value="contact@demo.example.com"/>
            <add key="siteUrl" value="http://demo.example.com"/>
        </appSettings>

    </configuration>

    Then we create another file, transform.xml, which contains our transformations. That file is shown below.

    <configuration xmlns:xdt="http://schemas.microsoft.com/XML-Document-Transform">
        <connectionStrings>
            <clear/>
            <add name="Default" connectionString="Data Source=NOT-localhost;Initial Catalog=Sample01;Integrated Security=True;"
                 xdt:Locator="Match(name)" xdt:Transform="Replace"/>
        </connectionStrings>

        <appSettings>
            <add key="contactEmail" value="contact@example.com" xdt:Locator="Match(key)" xdt:Transform="Replace"/>
            <add key="siteUrl" value="http://example.com" xdt:Locator="Match(key)" xdt:Transform="Replace"/>
        </appSettings>

    </configuration>

    Then we can easily execute the transformations by using MSBuild. So I created a file named trans.proj and it is shown below.

    <Project ToolsVersion="4.0" DefaultTargets="Demo" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
        <UsingTask TaskName="TransformXml"
                 AssemblyFile="$(MSBuildExtensionsPath)\Microsoft\VisualStudio\v10.0\Web\Microsoft.Web.Publishing.Tasks.dll"/>

        <Target Name="Demo">
            <TransformXml Source="app.config"
                          Transform="Transform.xml"
                          Destination="app.prod.config"/>
        </Target>
    </Project>

    This MSBuild file uses the TransformXml task which is shipped with Visual Studio 2010. We specify the source file, transform file and the destination. Pretty straight forward.

    In order to execute this I open a Visual Studio 2010 command prompt, browse to the directory containing both files, and enter the following command

    msbuild trans.proj /t:Demo

    Once you do this then you will find the file app.prod.config with the following contents.

    <configuration>
        <connectionStrings>
            <clear/>
            <add name="Default" connectionString="Data Source=NOT-localhost;Initial Catalog=Sample01;Integrated Security=True;"/>
        </connectionStrings>

        <appSettings>
            <add key="contactEmail" value="contact@example.com"/>
            <add key="siteUrl" value="http://example.com"/>
        </appSettings>

    </configuration>

    Sayed Ibrahim Hashimi

    Config-Transformation | msbuild | MSBuild 4.0 | MSDeploy | Visual Studio | Visual Studio 2010 Monday, April 26, 2010 5:22:06 AM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, March 19, 2010

    Replacing solution files with MSBuild Files

    I recently answered a question on stackoverflow.com Replace .sln with MSBuild and wrap contained projects into targets and wanted to share that content here as well. I’ll expand a bit more on it here.

    A couple common questions that I’m frequently asked include

    1. Should I use solution files for public builds
    2. How can I replace a solution file with an MSBuild file

    My answer for 1 is that I never use .sln files for any public build. I always create my own build file and use that. My take on solution files is that they are for developer convince for use in Visual Studio only. If you disagree, you are not alone.

    Replacing a solution file with an MSBuild file is pretty easy, you just create an MSBuild file to build your projects. You will do that by using the MSBuild task. Now if you want to create a reusable .targets file (or set of .targets files) then this is a bit more involved, but makes it easier on you in the long haul.

    I wrote about 20 pages on creating reusable .targets files in my book, but I'll get you started here with the basics here. I believe that the key to creating reusable build scripts (i.e. .targets files) is three elements:

    The idea is that you want to place all of your targets into separate files and then these files will be imported by the files which will be driving the build process. These are the files which contain the data. Since you import the .targets files you get all the targets as if they had been defined inline. There will be a silent contract between the .proj and .targets files. This contract is defined in properties and items which both use. This is what needs to be validated.

    The idea here is not new. This pattern is followed by .csproj (and other projects generated by Visual Studio). If you take a look your .csproj file you will not find a single target, just properties and items. Then towards the bottom of the file it imports Microsoft.csharp.targets (may differ depending on project type). This project file (along with others that it imports) contains all the targets which actually perform the build.

    So it's layed out like this:

    Where MyProdcut.proj might look like:

    <?xml version="1.0" encoding="utf-8"?>
    <Project DefaultTargets="Build" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
      <!-- This uses a .targets file to off load performing the build -->
      <PropertyGroup>
        <Configuration Condition=" '$(Configuration)'=='' ">Release</Configuration>
        <OutputPath Condition=" '$(OutputPath)'=='' ">$(MSBuildProjectDirectory)\BuildArtifacts\bin\</OutputPath>
      </PropertyGroup>

      <ItemGroup>
        <Projects Include="$(MSBuildProjectDirectory)\..\ClassLibrary1\ClassLibrary1.csproj"/>
        <Projects Include="$(MSBuildProjectDirectory)\..\ClassLibrary2\ClassLibrary2.csproj"/>
        <Projects Include="$(MSBuildProjectDirectory)\..\ClassLibrary3\ClassLibrary3.csproj"/>
        <Projects Include="$(MSBuildProjectDirectory)\..\WindowsFormsApplication1\WindowsFormsApplication1.csproj"/>
      </ItemGroup>

      <Import Project="SharedBuild.targets"/>
    </Project>

    And SharedBuild.targets might look like:

    <Project  DefaultTargets="Build" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">
      <!-- This represents a re-usable build file -->
      <Target Name="SharedBuild_Validate">
        <!-- See http://sedodream.com/2009/06/30/ElementsOfReusableMSBuildScriptsValidation.aspx for more info
             about this validation pattern
        -->
        <ItemGroup>
          <_RequiredProperties Include ="Configuration">
              <Value>$(Configuration)</Value>
          </_RequiredProperties>
          <_RequiredProperties Include ="OutputPath">
              <Value>$(OutputPath)</Value>
          </_RequiredProperties>

          <_RequiredItems Include="Projects">
            <RequiredValue>%(Projects.Identity)</RequiredValue>
            <RequiredFilePath>%(Projects.Identity)</RequiredFilePath>
          </_RequiredItems>
        </ItemGroup>

        <!-- Raise an error if any value in _RequiredProperties is missing -->
        <Error Condition="'%(_RequiredProperties.Value)'==''"
               Text="Missing required property [%(_RequiredProperties.Identity)]"/>

        <!-- Raise an error if any value in _RequiredItems is empty -->
        <Error Condition="'%(_RequiredItems.RequiredValue)'==''"
               Text="Missing required item value [%(_RequiredItems.Identity)]" />

        <!-- Validate any file/directory that should exist -->
        <Error Condition="'%(_RequiredItems.RequiredFilePath)' != '' and !Exists('%(_RequiredItems.RequiredFilePath)')"
               Text="Unable to find expeceted path [%(_RequiredItems.RequiredFilePath)] on item [%(_RequiredItems.Identity)]" />
      </Target>

      <PropertyGroup>
        <BuildDependsOn>
          SharedBuild_Validate;
          BeforeBuild;
          CoreBuild;
          AfterBuild;
        </BuildDependsOn>
      </PropertyGroup>
      <Target Name="Build" DependsOnTargets="$(BuildDependsOn)"/>
      <Target Name="BeforeBuild"/>
      <Target Name="AfterBuild"/>
      <Target Name="CoreBuild">
        <!-- Make sure output folder exists -->
        <PropertyGroup>
          <_FullOutputPath>$(OutputPath)$(Configuration)\</_FullOutputPath>
        </PropertyGroup>
        <MakeDir Directories="$(_FullOutputPath)"/>
        <MSBuild Projects="@(Projects)"
                 BuildInParallel="true"
                 Properties="OutputPath=$(_FullOutputPath)"/>
      </Target>
    </Project>

    Don't look too much at the SharedBuild_Validate target yet. I put that there for completeness but don't focus on it. You can find more info on that at my blog at http://sedodream.com/2009/06/30/ElementsOfReusableMSBuildScriptsValidation.aspx.

    The important parts to notice are the extensibility points. Even though this is a very basic file, it has all the components of a reusable .targets file. You can customize it's behavior by passing in different properties and items to build. You can extend it's behavior by overriding a target (BeforeBuild, AfterBuild or even CoreBuild) and you can inject your own targets into the build with:

    <Project ...>
       ...
      <Import Project="SharedBuild.targets"/>
      <PropertyGroup>
        <BuildDependsOn>
          $(BuildDependsOn);
          CustomAfterBuild
        </BuildDependsOn>
      </PropertyGroup>
      <Target Name="CustomAfterBuild">
        <!-- Insert stuff here -->
      </Target>
    </Project>

    So this is the basics on how to create reusable build scripts which can help you easily create .proj files to replace your .sln files. I also recently answered. a related question Make a target run once at the Solution level in MSBuild.

    This samples for this are using Visual Studio 2010 RC You can download the samples for this at http://sedotech.com/Content/files/ReplaceSlnFile.zip

    Sayed Ibrahim Hashimi

    msbuild | Visual | Visual Studio | Visual Studio 2010 Friday, March 19, 2010 4:16:06 AM (GMT Standard Time, UTC+00:00)  #     |
    Thursday, August 13, 2009

    MSBuild: Executing MSTest Unit Tests

    I have seen a couple blog entries about executing MSTest unit tests from MSBuild. Most recently I saw the entry by Scott A. Lawrence. So I decided to share how I execute MSTest unit tests from MSBuild

    I created a file named Build.Common.UnitTest.targets which contains all the behavior that will execute the test cases. This file can then be imported into whatever scripts that need to execute test cases. The entire file is shown below. We will discuss afterwards.

    Build.Common.UnitTest.targets

    <?xml version="1.0" encoding="utf-8"?>

    <Project ToolsVersion="3.5" DefaultTargets="Build" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <!-- =======================================================================

        TESTING

      ======================================================================= -->



      <!-- Default build settings go here -->

      <PropertyGroup>

        <RunMSTest Condition="'$(RunMSTest)'==''">true</RunMSTest>

        <BuildInParallel Condition="'$(BuildInParallel)'==''">true</BuildInParallel>

      </PropertyGroup>



      <Target Name="MSTestValidateSettings">

        <!-- Cleare out these items -->

        <ItemGroup>

          <_RequiredProperties Remove="@(_RequiredProperties)"/>

          <_RequiredItems Remove="@(_RequiredItems)"/>

        </ItemGroup>



        <ItemGroup>

          <_RequiredProperties Include="BuildContribRoot">

            <Value>$(BuildContribRoot)</Value>

          </_RequiredProperties>

          <_RequiredProperties Include="OutputRoot">

            <Value>$(OutputRoot)</Value>

          </_RequiredProperties>



          <_RequiredItems Include="MSTestProjects">

            <RequiredValue>@(MSTestProjects)</RequiredValue>

            <RequiredFilePath>%(MSTestProjects.FullPath)</RequiredFilePath>

          </_RequiredItems>

          <_RequiredItems Include="AllConfigurations">

            <RequiredValue>@(AllConfigurations)</RequiredValue>

          </_RequiredItems>

          <_RequiredItems Include="AllConfigurations.Configuration">

            <RequiredValue>%(AllConfigurations.Configuration)</RequiredValue>

          </_RequiredItems>

        </ItemGroup>



        <!-- Raise an error if any value in _RequiredProperties is missing -->

        <Error Condition="'%(_RequiredProperties.Value)'==''"

               Text="Missing required property [%(_RequiredProperties.Identity)]"/>



        <!-- Raise an error if any value in _RequiredItems is empty -->

        <Error Condition="'%(_RequiredItems.RequiredValue)'==''"

               Text="Missing required item value [%(_RequiredItems.Identity)]" />



        <!-- Validate any file/directory that should exist -->

        <Error Condition="'%(_RequiredItems.RequiredFilePath)' != '' and !Exists('%(_RequiredItems.RequiredFilePath)')"

               Text="Unable to find expeceted path [%(_RequiredItems.RequiredFilePath)] on item [%(_RequiredItems.Identity)]" />

      </Target>



      <UsingTask

          TaskName="TestToolsTask"

          AssemblyFile="$(BuildContribRoot)TestToolsTask-1.3\Microsoft.VisualStudio.QualityTools.MSBuildTasks.dll"/>



      <!-- TODO: Create a ValidateTestSettings target and put it on this list -->

      <PropertyGroup>

        <MSTestDependsOn>

          BuildMSTestProjects;

          BeforeMSTest;

          CoreMSTest;

          AfterMSTest

          $(MSTestDependsOn);

        </MSTestDependsOn>

      </PropertyGroup>

      <Target Name="MSTest" DependsOnTargets="$(MSTestDependsOn)"/>

      <Target Name="BeforeMSTest"/>

      <Target Name="AfterMSTest"/>

      <Target Name="CoreMSTest" Outputs="%(MSTestProjects.Identity)">

        <Message Text="Running MSTest for project [%(MSTestProjects.Identity)]"/>

        <Message Text="MSTestProjects.Directory: %(MSTestProjects.RootDir)%(MSTestProjects.Directory)" />



        <PropertyGroup>

          <_CurrentConfig>Debug</_CurrentConfig>

        </PropertyGroup>



        <PropertyGroup>

          <_SearchPath>$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\</_SearchPath>

          <_TestContainers></_TestContainers>

        </PropertyGroup>



        <TestToolsTask

          SearchPathRoot="%(MSTestProjects.RootDir)%(MSTestProjects.Directory)"

          TestContainers="$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\bin\%(MSTestProjects.Filename).dll"/>



        <!-- TODO: Read in the results of the tests and get all failures and report them here -->

      </Target>



      <PropertyGroup>

        <BuildMSTestProjectsDependsOn>

          BeforeBuildMSTestProjects;

          CoreBuildMSTestProjects;

          AfterBuildMSTestProjects;

          $(BuildMSTestProjectsDependsOn);

        </BuildMSTestProjectsDependsOn>

      </PropertyGroup>

      <Target Name="BuildMSTestProjects" DependsOnTargets="$(BuildMSTestProjectsDependsOn)"/>

      <Target Name="BeforeBuildMSTestProjects"/>

      <Target Name="AfterBuildMSTestProjects"/>

      <Target Name="CoreBuildMSTestProjects" Outputs="%(AllConfigurations.Configuration)"

              DependsOnTargets="CleanMSTest">

        <!-- Make sure to do clean build in case test cases were added -->



        <PropertyGroup>

          <_CurrentConfig>%(AllConfigurations.Configuration)</_CurrentConfig>

        </PropertyGroup>



        <Message Text="Building (MSTestProjects.Identity) %(MSTestProjects.Identity)" Importance="high"/>



        <!-- Build the projects here. -->

        <MSBuild Projects="%(MSTestProjects.Identity)"

                 Properties="Configuration=$(_CurrentConfig);

                              OutputPath=$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\bin\;

                              BaseIntermediateOutputPath=$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\obj\;

                              GenerateResourceNeverLockTypeAssemblies=true;

                              %(ProjectsToBuild.Properties);

                              $(AllProjectProperties);"

                 BuildInParallel="$(BuildInParallel)"

                 >

        </MSBuild>

      </Target>





      <Target Name="CleanMSTest">



        <MSBuild Projects="@(MSTestProjects)"

             Targets="Clean"

             Properties="Configuration=$(_CurrentConfig);

                              OutputPath=$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\bin\;

                              BaseIntermediateOutputPath=$(OutputRoot)$(_CurrentConfig)\%(MSTestProjects.Filename)\obj\;

                              GenerateResourceNeverLockTypeAssemblies=true;"

             BuildInParallel="$(BuildInParallel)"

                 />



      </Target>



    </Project>

    There are five important targets which are described below.

    Name

    Description

    MSTestValidateSettings

    This validates that the file was provided the needed data values to perform its task, to run the unit tests. For more info on this technique see my previous entry Elements of Reusable MSBuild Scripts: Validation.

    MSTest

    This is the target that you would execute to run the test cases. The target itself is empty but it sets up the chain of dependent targets.

    CoreMSTest

    This is the target which executes the test cases. This is preformed using the TestToolsTask.

    BuildMSTestProjects

    This target is responsible for building (i.e. compiling) the projects which contain the test cases. You don't have to call this it is called automagically.

    CleanMSTest

    This target will execute the Clean target for all the test projects defined.



    If you take a look at the CoreBuildMSTestProjects target you can see that I am batching (Target batching to be specific) it on each defined configuration. This is achieved with the attribute Outputs="%(AllConfigurations.Configuration)". If you are not familiar with batching, see the links at the end of this post for more details, and you can always grab my book for even more detailed info J. Then inside that target I build each project by batching (Task batching) the MSBuild task on each project defined in the MSTestProjects item list.

    Then inside the CoreMSTest target I execute the test cases. This target is batched for every value in the MSTestProjects item. As I'm writing this I have noticed that I've hard-coded the value for the configuration used in that target to be Debug with the statement

    <PropertyGroup>

      <_CurrentConfig>Debug</_CurrentConfig>

    </PropertyGroup>

    This shouldn't be hard coded, but passed in. I will leave it as is for now though. Then the TestToolsTask is invoked to execute the test cases.

    Now that we have written the re-usable .targets file to execute the test cases we need to create a file which will "feed" it the necessary data values and let it do its magic. I created a sample solution, which you can download at the end of this post, which demonstrates its usage. The solution is named MSTestExample and you can see the files it contains in the screen shot below.

    Here I've highlighted the two MSTest projects as well as a couple build files. I've already shown the contents of the Build.Common.UnitTest.targets file. Here is the contents of the Build.MSTestExample.proj file.

    Build.MSTestExample.proj

    <?xml version="1.0" encoding="utf-8"?>

    <Project ToolsVersion="3.5" DefaultTargets="MSTest" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">



      <!--

      Some properties you may be interested in setting:

        Name              Description

        *****************************************************

        RunMSTest         true/false to run unit tests or not

      -->



      <PropertyGroup>

        <Root Condition="'$(Root)'==''">$(MSBuildProjectDirectory)\..\</Root>



        <BuildRoot Condition="'$(BuildRoot)'==''">$(Root)Build\</BuildRoot>

        <BuildContribRoot Condition="'$(BuildContribRoot)'==''">$(BuildRoot)Contrib\</BuildContribRoot>



        <SourceRoot Condition="'$(SourceRoot)'==''">$(Root)</SourceRoot>

        <BuildArtifactsRoot Condition="'$(BuildArtifactsRoot)'==''">$(BuildRoot)BuildAftifacts\</BuildArtifactsRoot>

        <OutputRoot Condition="'$(OutputRoot)'==''">$(BuildArtifactsRoot)Output\</OutputRoot>

        <TreatWarningsAsErrors Condition=" '$(TreatWarningsAsErrors)'=='' ">true</TreatWarningsAsErrors>

      </PropertyGroup>



      <PropertyGroup>

        <CodeAnalysisTreatWarningsAsErrors Condition="'$(CodeAnalysisTreatWarningsAsErrors)'==''">true</CodeAnalysisTreatWarningsAsErrors>

        <BuildInParallel Condition="'$(BuildInParallel)'==''">true</BuildInParallel>



        <RunCodeAnalysis Condition="'$(RunCodeAnalysis)'==''">true</RunCodeAnalysis>

        <RunMSTest Condition="'$(RunMSTest)'==''">false</RunMSTest>

        <RunStyleCop Condition="''=='$(RunStyleCop)'">true</RunStyleCop>

      </PropertyGroup>



      <!-- Configurations that we want to build for -->

      <ItemGroup>

        <AllConfigurations Include="Debug">

          <Configuration>Debug</Configuration>

        </AllConfigurations>

      </ItemGroup>



      <!-- =======================================================================

        MSTest

      ======================================================================= -->



      <ItemGroup>

        <MSTestProjects Include="$(SourceRoot)TestProject1\TestProject1.csproj">

        </MSTestProjects>

        <MSTestProjects Include="$(SourceRoot)TestProject2\TestProject2.csproj">

        </MSTestProjects>

      </ItemGroup>



      <Import Project="$(BuildRoot)Build.Common.UnitTest.targets"/>



      <!-- Inject the MSTest targets into the build -->

      <!--<PropertyGroup Condition="'$(RunMSTest)'=='true'">

        <BuildDependsOn>

          $(BuildDependsOn);

          MSTest;

        </BuildDependsOn>

        <BuildMSTestProjectsDependsOn>

          CoreBuild;

          $(BuildMSTestProjectsDependsOn)

        </BuildMSTestProjectsDependsOn>

      </PropertyGroup>-->



    </Project>

    This file is pretty simple. It just creates some properties, and items and then just imports the Build.Common.UnitTest.targets file to do all the heavy lifting. You will probably notice that there are some properties defined that don't make sense here, like CodeAnalysisTreatWarningsAsErrors, this is because this was taken from a build script which does some other tasks. You can ignore those. To see what properties/items are required for the MSTest just look at the MSTestValidateSettings target. Also in the previous code snippet I showed how you could inject the MSTest target into the build process but it is commented out since there is no real build process in this case.

    One thing about this approach that may not be ideal is that it will execute the test cases in one assembly at a time and if there is a failure it will not go on to the other assemblies. In my case this is OK because this is for local builds, public builds are executing test cases by Team Build, but this can be looked at.

    Questions? Comments?



    MSTestExamples.zip

    MSBuild Batching Links


    Sayed Ibrahim Hashim

    batching | msbuild | Visual Studio | Visual Studio 2008 Thursday, August 13, 2009 5:11:52 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, May 26, 2009

    Visual Studio 2010: When *Might* it be Available

    Before I begin this post I must say that I do not have any inside information about the release of Visual Studio 2010 or .NET 4. The post is composed of 100 % speculation and based on information that has already been made publicly available.

    I am pretty interested to know the release date for Visual Studio 2010, and .NET Framework 4.0, so I asked around but no one could tell me anything. So I decided to do some research as to the release dates for Visual Studio 2005 and Visual Studio 2008 based on the release of their Beta releases. I came up with the following table.



    Beta 1

    Beta 2

    RTM

    Beta 1 - Beta 2

    Beta 2 - RTM

    Visual Studio 2005

    06/29/2004

    04/18/2005

    11/07/2005

    43 Weeks

    29 Weeks

    Visual Studio 2008

    04/19/2007

    07/26/2007

    11/19/2007

    14 Weeks

    17 Weeks

    Visual Studio 2010

    05/18/2009

    11/30/2009

    05/09/2010

    28 Weeks

    20 Weeks

    Yellow cells are 100% based just on the averages of the two previous versions



    When Visual Studio 2005 came out there were huge changes. I think this is why the amount of time between Beta 1 and Beta 2, and between Beta 2 and RTM were so much longer then their corresponding periods in Visual Studio 2008. I think for the release of Visual Studio 2010 we are going to be somewhere between the two time periods. So maybe a decent indicator would simply be the average of the two. This is what I used to come up with the cells that are shaded in yellow. I'm sure this will be off but hopefully by weeks and not months!



    Sayed Ibrahim Hashimi

    msbuild | Visual Studio | Visual Studio 2008 Tuesday, May 26, 2009 4:24:49 AM (GMT Daylight Time, UTC+01:00)  #     |
    Monday, June 16, 2008

    Changing Build Verbosity in Visual Studio

    If you are customizing your build process you may need to increase the verbosity that Visual Studio uses when building your projects. It is pretty easy to change this value, you just go to Tools->Options then find the Project and Solutions->Build and Run node. The dialog is shown here

    The area where the verbosity setting lies is highlighted. I've got mine set to Detailed, which produces a lot of output. If you set it to Diagnostic, then you should be ready for a lot of output. Most like much more then you need!


    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Monday, June 16, 2008 6:50:26 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, May 08, 2008

    MSBuild: Building the same project multiple times

    After some discussion at the MSBuild MSDN Forum I started investigating building the same project with different Compiler constants defined. I was actually pretty surprised by what I found. I created a simple Windows Form Application with a lone button one it. The image below show the simple app.

    Here is the entire code behind file.

    using System;

    using System.Collections.Generic;

    using System.ComponentModel;

    using System.Data;

    using System.Drawing;

    using System.Linq;

    using System.Text;

    using System.Windows.Forms;



    namespace WindowsFormsApplication1

    {

    public partial class Form1 : Form

    {

    public Form1()

    {

    InitializeComponent();

    }



    private void buttonExample_Click(object sender, EventArgs e)

    {

    string message = "default message";

    #if CONSTANT_ONE

    message = "CONSTANT_ONE";

    #endif

    #if CONSTANT_TWO

    message = "CONSTANT_TWO";

    #endif



    MessageBox.Show(message);

    }

    }

    }

    Ddd

    The parts to take note are the regions highlighted in yellow. So if the constant CONSTANT_ONE is defined the message results to CONSTANT_ONE and if CONSTANT_TWO is defined it will show the message CONSTANT_TWO.

    I then created the simple build file.

    <?xml version="1.0" encoding="utf-8"?>

    <Project DefaultTargets="BuildAll" ToolsVersion="3.5"

    xmlns="http://schemas.microsoft.com/developer/msbuild/2003">



    <PropertyGroup>

    <ConstOne>CONSTANT_ONE</ConstOne>

    <ConstTwo>CONSTANT_TWO</ConstTwo>

    </PropertyGroup>



    <ItemGroup>

    <Projects Include="$(MSBuildProjectDirectory)\..\WindowsFormsApplication1\WindowsFormsApplication1.csproj">

    </Projects>

    </ItemGroup>



    <!--

    Cleans the project before we start the build process.

    The only reason I am calling this is to remove artifacts of

    previous builds, to clearly demonstrate what's going on.

    -->

    <Target Name="CleanAll">

    <MSBuild Projects="@(Projects)" Targets="Clean" />

    </Target>



    <Target Name="BuildAll" DependsOnTargets="CleanAll;BuildConstOne;BuildConstTwo" />



    <Target Name="BuildConstOne">

    <MSBuild Projects="@(Projects)"

    Properties="DefineConstants=$(ConstOne);OutputPath=binOne\;"/>

    </Target>

    <Target Name="BuildConstTwo">

    <MSBuild Projects="@(Projects)"

    Properties="DefineConstants=$(ConstTwo);OutputPath=binTwo\;"



    />

    </Target>



    <!-- ===========================================================================

    This region rebuilds the projects, so after it is built once it is then cleaned

    before building it again.

    This produces the assemblies with the desired behavior

    ================================================================================-->



    <Target Name="ReBuildAll" DependsOnTargets="CleanAll;ReBuildConstOne;ReBuildConstTwo" />

    <Target Name="ReBuildConstOne">

    <MSBuild Projects="@(Projects)" Targets="Rebuild"

    Properties="DefineConstants=$(ConstOne);OutputPath=binOne\;"/>

    </Target>

    <Target Name="ReBuildConstTwo">

    <MSBuild Projects="@(Projects)" Targets="Rebuild"

    Properties="DefineConstants=$(ConstTwo);OutputPath=binTwo\;"/>

    </Target>



    <!--==========================================================================

    This region calls the default target (Build) but also specifies the

    BaseIntermediateOutputPath so it works as well because the projects

    are building to different locations on disk.

    ==============================================================================-->

    <Target Name="BuildAllBetter" DependsOnTargets="CleanAll;BuildConstOneBetter;BuildConstTwoBetter" />

    <Target Name="BuildConstOneBetter">

    <MSBuild Projects="@(Projects)"

    Properties="DefineConstants=$(ConstOne);OutputPath=binOne\BaseIntermediateOutputPath=objOne\"/>

    </Target>

    <Target Name="BuildConstTwoBetter">

    <MSBuild Projects="@(Projects)"

    Properties="DefineConstants=$(ConstTwo);OutputPath=binTwo\;BaseIntermediateOutputPath=objTwo\;"



    />

    </Target>



    </Project>

    Ddddd

    Let's take a look at what's going on here. The BuildConstOne target passes the CONSTANT_ONE value as a property when invoking the MSBuild task, and builds to the binOne folder. The BuildConstTwo target passes the CONSTANT_TWO value and builds to binTwo. If you execute the target BuildAll, you would expect that the exe in binOne would show the message CONSTANT_ONE and the exe in the binTwo folder has CONSTANT_TWO message showing. What you actually get is that both actually show CONSTANT_ONE. This is because MSBuild doesn't entirely rebuild the project when building it for the second time in BuildConstTwo. The real reason behind this would be because both projects are building to the same BaseIntermediateOutputPath, obj\. There are two ways to of getting around this, one is to call Rebuild instead of Build, and the other is to specify the BaseIntermediateOutputPath as well. In the above I have demonstrated both approaches. The ReBuildAll calls Rebuild, and the BuildAllBetter specifies the BaseIntermediateOutputPath as well as OutputPath.

    Questions?!

    You can download all the files at:

    DefineConst.zip

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Thursday, May 08, 2008 12:52:14 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, April 29, 2008

    How to debug MSBuild tasks

    A question that comes up pretty frequently is "How can I debug an MSBuild task"? It's actually pretty simple. In this post I will describe how to easily an effectively debug MSBuild tasks that you are creating. In this example I will be demonstrating a task from my open source tasks at www.codeplex.com/Sedodream. The task is one that was contributed by Grant Holliday.

    First in the project where your tasks are contained create a folder that will be used to contain sample MSBuid files that can be used to debug the tasks. This is also a good idea, because it will show people how to use your tasks. If you are don't want to mix samples & code in the same project then just make sure in your build you copy the files to the correct locations. In the sample project, which you can download at the bottom, the folder is named Samples. When you add MSBuild files to the folder make sure you set the file to be copied to the output folder as well. See the image below.

    By setting this, the file will be copied to the output folder when the project is built. Since it will be in the output folder we can use a relative path to get to the assembly that contains the task. Take a look at the sample MSBuild file for this task.

    <?xml version="1.0" encoding="utf-8"?>

    <Project ToolsVersion="3.5" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

       <PropertyGroup>

        <TaskLocation Condition="$(TaskLocation)==''">$(MSBuildProjectDirectory)\..\DebugTask.dll</TaskLocation>

      </PropertyGroup>

       <UsingTask TaskName="CreateGuid" AssemblyFile="$(TaskLocation)"/>



      <Target Name="Example">

        <Message Text="Starting example" />

        <CreateGuid>

            <Output PropertyName="Guid" TaskParameter="Output"/>

          </CreateGuid>

        <Message Text="Guid: $(Guid)" />

       </Target>

    </Project>



    The line highlighted contains the path to the assembly that contains the task. This path is relative to the location in the output folder, not the source folder. Also another thing to take note, is that we only write to the TaskLocation property if it is empty. This is useful because you can overwrite the location through command line parameters if necessary. But this shouldn't be needed for what we are trying to accomplish here.

    After you create the sample, build the solution. And open a command prompt to verify that it works. Here is a sample of the result of this project file.

    Once you've verified that that MSBuild file works then you can right click on the project that contains your task, and select properties. From there go to the debug tab. What we want to do is start the msbuild.exe executable on that sample project file. To do this fill in the full path to it in the Start External program text box, i.e. 'C:\WINDOWS\Microsoft.NET\Framework\v3.5\MSBuild.exe'. In the command line arguments you should pass the name of the project file followed by any msbuild parameters. Typically I will attach a file logger to the process. Finally you should set the working directory to the folder containing the sample. The result should look something like the image shown below.

    Following this set a break point in your task, set the project as the startup project and hit F5! Another thing to take note of is that these properties are stored in the .user file so it shouldn't affect any other developers on your team.

    Below is the link containing a simple solution that was used here.



    DebugTask.zip

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Tuesday, April 29, 2008 6:10:03 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, April 15, 2008

    MSBuild + JSLint = Good Javascript

    Recently I was introduced to a tool that was to a tool that would analyze Javascript for syntactical errors as well as usage of bad practices. This tool is JSLint. Douglas Crockford from Yahoo! created, and maintains, JSLint. If you haven't heard of him, he is a well known Javascript expert.

    Now how can we verify our Javascript with JSLint & MSBuild? In my open source project Sedodream MSBuild I have created a new JSLint task. You can get the installer by going to http://www.codeplex.com/Release/ProjectReleases.aspx?ProjectName=Sedodream&ReleaseId=12530. After you install the msi you can follow these steps to invoke the JSLint on your projects.

    Edit your web project file and include the following snippet before the </Project> tag.

    <Import Project="$(MSBuildExtensionsPath)\Sedodream\Sedodream.tasks"/>

    <Import Project="$(MSBuildExtensionsPath)\Sedodream\JSLint.targets"/>



    <PropertyGroup>

    <BuildDependsOn>

    $(BuildDependsOn);

    RunJSLint;

    </BuildDependsOn>

    </PropertyGroup>



    The first line includes makes the tasks from my project available, and the second line includes the file that knows how to execute the JSLint tool. Following that I extend the build process to execute the RunJSLint target. If you are not familiar with this take a look at my article Inside MSBuild.

    After you do this you may be prompted with a security warning from Visual Studio, you should pick 'Load Project Normally'. You can read more about how to disable it at http://msdn2.microsoft.com/en-us/library/ms228217.aspx. I chose to not have my installer set that registry flag. For the time being I think that users should make that decision themselves, although I would like to think I'm trustworthy J

    After you do this and allow Visual Studio to load the project normally, if your create Javascript files that have errors, or JSLint doesn't like you will be warned in the error list as shown below.



    With that being said keep in mind this is a V1 deal, so this may not work perfect. I am working to make sure that it works well, but it was kinda tricky to get this to work period!

    As always I welcome your feedback and I will post more info about this later. Oh yeah by default from JSLint the GoodParts are enforced keep an eye on this blog, or send me a message, to see how to change that.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio | Javascript Tuesday, April 15, 2008 6:25:01 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, February 20, 2008

    MSBuild: Part 1 - QuickStart

    Previously I was thinking of writing some more material on MSBuild. Since then I have written about 60 pages of new material, and have actually decided to focus on some new topics. Because of this I will release a mulit part series that consists of this material that I have written. I think that I've come up with some pretty good content and would like to make it available. It still requires polishing and changes for this new format. So this is the first in this series of post.

    These first posts will be from the MSBuild Quick Start chapter

    In this post we will discuss the topics highlighted.

    MSBuild Quick Start

    MSBuild Quick Start

    When you are learning a new subject it's exciting to get just dive right into it and get your hands dirty. In this section I will describe all the key elements you will need to know to get started using MSBuild. If you are already familiar with MSBuild feel free to skip this section, all of the material covered here will be covered in later sections as well.

    The topics that we will cover in this section include; structure of an MSBuild file, Properties, Targets, Items and invoking MSBuild. With that being said, let's get started.

    Project file details

    An MSBuild file, typically called an MSBuild project file is really an XML file. These XML files are described by two XMLSchema Documents (XSD). These are located in the %WINDIR%\Microsoft.NET\Framework\v2+\MSBuild folder. Where v2+ is the version folder for .NET 2 and above. In this text I will assume you are using .NET 2.0 unless specified. In those folders you will find Microsoft.Build.Commontypes.xsd, this is the file that describes commonly found element in Visual Studio generated project files. Also this file includes the Microsoft.Build.Core.xsd document. This document describes all the fixed elements in an MSBuild project file. The simplest MSBuild file would contain the following:

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    </Project>

    This is the XML fragment that will identify this as an MSBuild file. Inside these tags is where all your content will be placed. Specifically we will be declaring Properties,Items, Targets and a few other items directly under the Project element. When you build you need to know what you are building, typically contained in Items and values that drive the build process, typically stored in Properties. We will now discuss how to declare properties, and we will cover Items later in this chapter.

    MSBuild Properties & Targets

    MSBuild properties are simply key value pairs, the key for the property is the name that you will use to refer to the property, and the value is, simply, its value. When you declare static properties they are contained in a PropertyGroup element directly under the Project element. Below is an example.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <PropertyGroup>

    <AppServer>\\sayedApp</AppServer>

    <WebServer>\\sayedWeb</WebServer>

    </PropertyGroup>

    </Project>

    In the snippet above I have declared two properties; AppServer and WebServer with the values '\\sayedApp' and '\\sayedWeb' respectively. You can create as many PropertyGroups under the Project tag as you desire. The above fragment could have been defined as the one shown below.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <PropertyGroup>

    <AppServer>\\sayedApp</AppServer>

    </PropertyGroup>

    <PropertyGroup>

    <WebServer>\\sayedWeb</WebServer>

    </PropertyGroup>

    </Project>

    If you create a sample project in Visual Studio, you will notice that there are many properties declared. These properties contain values that will be used throughout the build process. Below is a fragment from a Windows Application project that I created using Visual Studio.

    <Project DefaultTargets="Build" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <PropertyGroup>

    <Configuration Condition=" '$(Configuration)' == '' ">Debug</Configuration>

    <Platform Condition=" '$(Platform)' == '' ">AnyCPU</Platform>

    <ProductVersion>8.0.50727</ProductVersion>

    <SchemaVersion>2.0</SchemaVersion>

    <ProjectGuid>{A71540FD-9949-4AC4-9927-A66B84F97769}</ProjectGuid>

    <OutputType>WinExe</OutputType>

    <AppDesignerFolder>Properties</AppDesignerFolder>

    <RootNamespace>WindowsApplication1</RootNamespace>

    <AssemblyName>WindowsApplication1</AssemblyName>

    </PropertyGroup>

    <PropertyGroup Condition=" '$(Configuration)|$(Platform)' == 'Debug|AnyCPU' ">

    <DebugSymbols>true</DebugSymbols>

    <DebugType>full</DebugType>

    <Optimize>false</Optimize>

    <OutputPath>bin\Debug\</OutputPath>

    <DefineConstants>DEBUG;TRACE</DefineConstants>

    <ErrorReport>prompt</ErrorReport>

    <WarningLevel>4</WarningLevel>

    </PropertyGroup>

    ....

    </Project>

    You can see that things such as the output type, name of the assembly and many other values are defined in properties. Defining properties is great, but completely useless without being able to use them. So we will move on to Target declarations.

    MSBuild has execution elements, those are Tasks and Targets. A Task is the smallest unit of work in and MSBuild file, and a Target is simply a sequential set of tasks. A Task must always be contained within target. Below is a sample that shows you the simplest MSBuild file which contains a target.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <Target Name="HelloWorld">

    </Target>

    </Project>

    In this sample we have created a new Target named HelloWorld, but it actually doesn't perform any work at this point because it is empty. When MSBuild is installed you are given many tasks out of the box. You can find a list of these tasks at MSBuild Task Reference (http://msdn2.microsoft.com/en-us/library/7z253716.aspx). We will now use the Message task. The message task is used to send a message to the logger(s) that are listening the build process. In many cases this means that a message is sent to the console that is executing the build process. When you invoke a task in an MSBuild file you can pass it input parameters by inserting XML attributes with values. These attributes will vary from task to task depending on what inputs the task is expecting. From the documentation for the Message task (http://msdn2.microsoft.com/en-us/library/6yy0yx8d.aspx) you can see that is accepts a string parameter named Text. The snippet below shows you how to use the Message task to send the value 'Hello World' to the logger(s).

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <Target Name="HelloWorld">

    <Message Text="Hello world!"/>

    </Target>

    </Project>

    Now we will verify that this works as expected. To do this place the above text into a file named HelloWorld.proj. Now open a Visual Studio Command Prompt and go to the directory that contains the newly created file. The shortcut for this prompt is in the Visual Studio Tools folder under the Visual Studio folder in the Start menu. The command that you'll use is the msbuild.exe command. The basic usage for the command is

    msbuild [INPUT_FILE] /t:[TARGETS_TO_EXECUTE]

    So our command would be

    msbuild HelloWorld.proj /t:HelloWorld

    In the above we are saying, build HelloWorld.proj by executing the HelloWorld target. The result of this command is shown in the image below.



    In the image above we can see that the HelloWorld target is executed and that a message 'Hello World!' was displayed on the console. Now let's see how we can use properties within other properties. Have a look at the simple project file shown below.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <PropertyGroup>

    <Configuration Condition=" '$(Configuration)' == '' ">Debug</Configuration>

    <Platform Condition=" '$(Platform)' == '' ">AnyCPU</Platform>

    <DropLocation>\\sayedData\MSBuildExamples\Drops\$(Configuration)\$(Platform)\</DropLocation>

    </PropertyGroup>

    <Target Name="PrepareFilesForDrop">

    <Message Text="DropLocation : $(DropLocation)"/>

    </Target>

    </Project>

    In the snippet above we can see that there are three properties that have been declared. On both the Configuration & Platform properties there is a Condition attribute. We will discuss these attributes later in this chapter. The remaining property, DropLocation, is defined using the values of the two previously declared items. Let's take a close look at that. The DropLocation Property has three components; a constant value and two values that are derived from the Configuration & Platform properties. When the MSBuild engine sees the $() notation it will replace that with the value of the specified properties. So the qualified DropLocation value would be: '\\sayedData\MSBuildExamples\Drops\Debug\AnyCPU\'. You can verify that by executing the PrepareFilesForDrop target from the Visual Studio Command Prompt. The reference for properties can be found at http://msdn2.microsoft.com/en-us/library/ms171458(VS.80).aspx.

    When you use MSBuild there are a handful of properties that are available to you out of the box, that cannot be modified. These are known as Reserved properties. In the table below you will find all the Reserved properties.

    Name

    Description

    Example

    MSBuildProjectDirectory

    Full path to the location of project file.

    C:\MSBuild\MSBuild1\MSBuild1

    MSBuildProjectFile

    Filename of the project file, including extension.

    MSBuild1.csproj

    MSBuildProjectExtension

    Extension of the project filename, including the initial dot.

    .csproj

    MSBuildProjectFullPath

    Full path to the project file including the filename.

    C:\MSBuild\MSBuild1\MSBuild1\MSBuild1.csproj

    MSBuildProjectName

    Name of the MSBuild project file excluding the file extension.

    MSBuild1

    MSBuildBinPath

    Full path of the .NET Framework MSBuild bin directory.

    %WINDIR%\Microsoft.NET\Framework\v2.0.50727

    MSBuildProjectDefaultTargets

    The value for the DefaultTargets attribute that is in the Project element.

    Build

    MSBuildExtensionsPath

    Full path to the MSBuild folder located in the Program Files directory. This is a great place to keep commonly used items.

    C:\Program Files\MSBuild



    You would use these properties just as you would properties that you have declared in your own project file. To see an example of this you can look at Visual Studio generated project files. When you initially create a new C# project you will find the import statement <Import Project="$(MSBuildBinPath)\Microsoft.CSharp.targets" /> towards the bottom. This import declaration is using the MSBuildBinPath reserved property to resolve the full path to the Microsoft.CSharp.targets file. This is the file that drives the build process for C# projects. We will discuss its contents in more detail later in the book. Now that we have an idea how to use properties we will move on to Items.

    Items

    Building applications usually means dealing with many files. Because of this there is a specific construct that is used when dealing with files, and that is what's called Items. Items are usually file references, but they actually can be used for other purposes as well. If you create a project using Visual Studio you may notice that you see many PropertyGroup elements as well as ItemGroup elements. The ItemGroup elements contain all the defined items. When you define a Property you are declaring a key/value pair, but when you declare an Item you declare Items that can potentially have many elements inside of them. Let's see the syntax in action.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <ItemGroup>

    <SolutionFile Include="..\MSBuildExamples.sln"/>

    </ItemGroup>

    <Target Name="PrintSolutionInfo">

    <Message Text="SolutionFile: @(SolutionFile)"/>

    </Target>

    </Project>

    In this file, ItemsSimple.proj, there is an ItemGroup that has a sub element SoultionFile. The ItemGroup is the element type that all statically declared Items must be placed. The name of the sub elements are the names of the actual Items. In the above sample we have declared an Item names SolutionFile. The SolutionFile element has an attribute attached to it, the Include attribute. This attribute determines what actual entries are contained within the Item. This is because an Item can contain multiple entries. The Include attribute can contain a single value or a comma separated list of values. We will see this demonstrated later in this chapter.

    In the target, PrintSolutionInfo, we can see the Item at use. Item evaluation syntax varies from Property syntax. To get the value of an item you will use the @() notation. The result of the build file, ItemsSimple.proj, is shown in the image below.

    In this case the Item, SolutionFile, contains a single entry. Now let's see the result if there were multiple files included in the item. The snippet below shows the modified version of the ItemsSimple.proj file.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <ItemGroup>

    <SolutionFile Include="..\MSBuildExamples.sln"/>

    </ItemGroup>

    <Target Name="PrintSolutionInfo">

    <Message Text="SolutionFile: @(SolutionFile)"/>

    </Target>



    <ItemGroup>

    <Compile Include="Form1.cs;Form1.Designer.cs;Program.cs;Properties\AssemblyInfo.cs" />

    </ItemGroup>

    <Target Name="PrintCompileInfo">

    <Message Text="Compile: @(Compile)"/>

    </Target>

    </Project>

    When you invoke the PrintCompileInfo target you will get the result 'Compile: Form1.cs;Form1.Designer.cs;Program.cs;Properties\AssemblyInfo.cs'. The Message tasks' Text parameter is a string value so the item is automatically converted, by MSBuild, into a string then passed to the task. This is done by concatenating all the entries separated by a ;. Later in the book I will demonstrate how you can customize this conversion process. Since the Include attribute can accept either one or many entries we could have actually defined the Compile Item as follows:

    <ItemGroup>

    <Compile Include="Form1.cs"/>

    <Compile Include="Form1.Designer.cs"/>

    <Compile Include="Program.cs"/>

    <Compile Include="Properties\AssemblyInfo.cs"/>

    </ItemGroup>

    When a Property declaration appears after a previous declaration, this results in the value of the Property to be overridden. Items act differently from this; you cannot remove entries or overwrite values contained in an Item. You can only append to them. This is why both of the above statements are equivalent. Typically Items refer to existing files, if this is the case you can use wild cards to automatically include whatever files meet the conditions contained in the include statement. You can use three wildcard elements with MSBuild: ?, *, and **. You can use ? to replace a single character with any character. For example, the include declaration Include="c?r.cs" would include the files car.cs, cbr.cs, ccr.cs, and so on. The * element can replace any location with zero or more characters. To change the previous example, Include="c*r.cs" would include car.cs, caar.cs, cr.cs, colorer.cs, and so on. The ** notation tells MSBuild to search the directories recursively for the pattern. For example, Include="src\**\*.cs" would include all the files under the src directory with .cs extensions.

    Another difference between Properties and Items is that Items can have metadata. Actually when you declare an Item each entry has a set of metadata associated with it out of the box. The table below outlines the well known metadata.

    Name

    Description

    FullPath

    Full path of this item including the filename.

    RootDir

    Root directory to which this item belongs.

    Filename

    Filename for this item, not including the extension.

    Extension

    File extension for this item.

    RelativeDir

    Path to this item relative to the current working directory.

    Directory

    Directory of the item without the root directory.

    RecursiveDir

    Used for items that were created using wildcards. This would be the directory that replaces the wildcard(s) statements that determine the directory.

    Identity

    Value for the item specified in the Include attribute.

    ModifiedTime

    Time this item was last modified.

    CreatedTime

    Time the item was created.

    AccessedTime

    Last time this item was accessed.



    The basic usage for accessing metadata values is described by the template shown below.

    @(ITEM_NAME->'%(METADATA_NAME)')

    Where ITEM_NAME is the name of the item and METADATA_NAME is the name of the metadata that you would like to retrieve. Consider the following example. Assume that you have the following files in a directory; Class1.cs,Class2.cs,Class3.cs and Class4.cs. The following project file, MetadataExample01.proj, shows how to access the Compile Items' Fullpath metadata.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003" DefaultTargets="PrintCompileInfo">

    <ItemGroup>

    <Compile Include="*.cs"/>

    </ItemGroup>

    <Target Name="PrintCompileInfo">

    <Message Text="Compile fullpath: @(Compile->'%(Fullpath)')"/>

    </Target>

    </Project>

    If you execute the PrintCompileInfo target you will see the following result.

    From the output shown in the figure above we can see that the full path for all the Compile items was sent to the console. Accessing the metadata in this manner is given the term Item Transformation. We will discuss transformations in much more detail in a later chapter. Before we move on to discuss MSBuild Conditions take a look at a simple Windows Application project file that was generated by Visual Studio. You should see many things that you recognize.

    <Project DefaultTargets="Build" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

    <PropertyGroup>

    <Configuration Condition=" '$(Configuration)' == '' ">Debug</Configuration>

    <Platform Condition=" '$(Platform)' == '' ">AnyCPU</Platform>

    <ProductVersion>8.0.50727</ProductVersion>

    <SchemaVersion>2.0</SchemaVersion>

    <ProjectGuid>{0F34CE5D-2AB0-49A9-8254-B21D1D2EFFA1}</ProjectGuid>

    <OutputType>WinExe</OutputType>

    <AppDesignerFolder>Properties</AppDesignerFolder>

    <RootNamespace>WindowsApplication1</RootNamespace>

    <AssemblyName>WindowsApplication1</AssemblyName>

    </PropertyGroup>

    <PropertyGroup Condition=" '$(Configuration)|$(Platform)' == 'Debug|AnyCPU' ">

    <DebugSymbols>true</DebugSymbols>

    <DebugType>full</DebugType>

    <Optimize>false</Optimize>

    <OutputPath>bin\Debug\</OutputPath>

    <DefineConstants>DEBUG;TRACE</DefineConstants>

    <ErrorReport>prompt</ErrorReport>

    <WarningLevel>4</WarningLevel>

    </PropertyGroup>

    <PropertyGroup Condition=" '$(Configuration)|$(Platform)' == 'Release|AnyCPU' ">

    <DebugType>pdbonly</DebugType>

    <Optimize>true</Optimize>

    <OutputPath>bin\Release\</OutputPath>

    <DefineConstants>TRACE</DefineConstants>

    <ErrorReport>prompt</ErrorReport>

    <WarningLevel>4</WarningLevel>

    </PropertyGroup>

    <ItemGroup>

    <Reference Include="System" />

    <Reference Include="System.Data" />

    <Reference Include="System.Deployment" />

    <Reference Include="System.Drawing" />

    <Reference Include="System.Windows.Forms" />

    <Reference Include="System.Xml" />

    </ItemGroup>

    <ItemGroup>

    <Compile Include="Form1.cs">

    <SubType>Form</SubType>

    </Compile>

    <Compile Include="Form1.Designer.cs">

    <DependentUpon>Form1.cs</DependentUpon>

    </Compile>

    <Compile Include="Program.cs" />

    <Compile Include="Properties\AssemblyInfo.cs" />

    <EmbeddedResource Include="Properties\Resources.resx">

    <Generator>ResXFileCodeGenerator</Generator>

    <LastGenOutput>Resources.Designer.cs</LastGenOutput>

    <SubType>Designer</SubType>

    </EmbeddedResource>

    <Compile Include="Properties\Resources.Designer.cs">

    <AutoGen>True</AutoGen>

    <DependentUpon>Resources.resx</DependentUpon>

    </Compile>

    <None Include="Properties\Settings.settings">

    <Generator>SettingsSingleFileGenerator</Generator>

    <LastGenOutput>Settings.Designer.cs</LastGenOutput>

    </None>

    <Compile Include="Properties\Settings.Designer.cs">

    <AutoGen>True</AutoGen>

    <DependentUpon>Settings.settings</DependentUpon>

    <DesignTimeSharedInput>True</DesignTimeSharedInput>

    </Compile>

    </ItemGroup>

    <Import Project="$(MSBuildBinPath)\Microsoft.CSharp.targets" />

    <!-- To modify your build process, add your task inside one of the targets below and uncomment it.

    Other similar extension points exist, see Microsoft.Common.targets.

    <Target Name="BeforeBuild">

    </Target>

    <Target Name="AfterBuild">

    </Target>

    -->

    </Project>

    msbuild | Visual Studio Wednesday, February 20, 2008 12:40:11 AM (GMT Standard Time, UTC+00:00)  #     |
    Thursday, January 17, 2008

    MSBuild Presentation Content

    Previously I blogged about an MSBuild Presentation that I was going to conduct at the JaxDug. I'm pleased to say that the presentation went well. I prepared a Powerpoint, but I decided to not use that and to discuss the various elements by example. I think that ended up being a lot more effective, and interesting than the Powerpoint would have been. You can find all the files for download below. The zip file contains all the files. The ppt is the Office 2003 version.

    MSBuild_Sayed_I_Hashimi_012008.zip

    MSBuild_Sayed_I_Hashimi_01-2008.pdf
    MSBuild_Sayed_I_Hashimi_01-2008.ppt.zip
    MSBuild_Sayed_I_Hashimi_01-2008.pptx.zip

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Thursday, January 17, 2008 6:57:31 AM (GMT Standard Time, UTC+00:00)  #     |
    Wednesday, November 21, 2007

    MSBuild: How to get all generated outputs

    MSBuild: How to get all generated outputs

    Earlier today a reader of my book emailed me the following question

    I am trying to get a list of all the files being generated when MSBuild build a  certain project (they should be all the files in .bin directory).

    When I used the TargetOutputs in MSBuild task it gives me the main output only, which is the .exe or .dll. But any other files like dependency assemblies will not be listed in the TargetOutputs collection.

    Any advice??

    So it sounds like he is looking for a generic way of determining all the files that have been created (moved) during the build process. I’m assuming that he has a few projects and is using a build script to run the process, and then he wants to move the files to another location. If you have a few projects, then obviously the easiest way is to manually examine the output paths of each project and copy the file as necessary. This is not an ideal scenario, because if you add a project to your process you have to make sure to remember to perform the copy manually. Anywayz, this type of behavior would be useful in many different scenarios. Now let’s talk about how to achieve this.

    I took another look at the Microsoft.Common.targets file and determined that there is not a straight forward method of performing this action. So, after thinking about this for a little while I think I have come up with a solution. It’s a little confusing, but actually quite simple.

    The solution lies in what I’m calling “MSBuild Inheritance”, which I’ve blogged about previously in the entries at:

    ·        MSBuild Property & Item Overide Problems

    ·        MSBuild: Find Many Project References

    This is where you take an existing MSBuild file and without modifying it you add behavior and or data to it. Now let’s see how this idea can be used to add the desired behavior described above. For this sample I have created a sample Windows Forms app, as well as an external build script, buildWrapper.proj. This build file is shown below.

    <Project DefaultTargets="GetOutputs" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <PropertyGroup>

        <ProjectFile>$(MSBuildProjectDirectory)\WindowsApplication1.csproj</ProjectFile>

      </PropertyGroup>



      <Target Name="GetOutputs">

        <MSBuild Projects="$(MSBuildProjectFullPath)"

                 Properties="ImportProjectFile=true" Targets="Build">

          <Output ItemName="ProjectOutputs" TaskParameter="TargetOutputs"/>

        </MSBuild>

        <Message Text="%0a%0dProjectOutputs:%0a%0d    @(ProjectOutputs,'%0a%0d    ')" />

      </Target>



      <!--

        These elements will only be processed when in the context of the

        above Target. This is because of the Condition constraint on these items

      -->

      <Import Project="$(ProjectFile)" Condition="'$(ImportProjectFile)'=='true'"/>

      <!--

        Here we need to override the Build target with our own that will

        generate the correct results.

        -->

      <Target Name="Build"

            Condition="'$(ImportProjectFile)'=='true'"

            DependsOnTargets="$(BuildDependsOn)"

            Outputs="@(AllOutputs->'%(FullPath)')">



        <CreateItem Include="$(OutputPath)\**\*">

          <Output ItemName="AllOutputs" TaskParameter="Include"/>

        </CreateItem>



        <Message Text="Custom build invoked!" Importance="high"/>



      </Target>

    </Project>

    What this does is twofold:

    1.      Defines the GetOutputs target which will drive the process

    2.      Extends the behavior of the normal build to create the proper outputs

    If you take a look at the Microsoft.Common.targets you will see that the default definition of the Build target is defined as follows:

        <Target

            Name="Build"

            Condition=" '$(_InvalidConfigurationWarning)' != 'true' "

            DependsOnTargets="$(BuildDependsOn)"

            Outputs="$(TargetPath)"/>

    The purpose of this target is to define what targets it depends on and to create the outputs, by itself it doesn’t actually perform any action. Because of this we can override it in our buildWrapper.proj file. So the bottom half of the buildWrapper.proj file will conditionally import the project file and then conditionally re-define the Build target. Inside the new Build target we simply examine the output directory and create an item that contains all files that lie underneath it. In the image below you will see the result of this, specifically take a look at the region highlighted in red.





    Now we can see that we have successfully achieved our goals.

    Every time I describe this process I feel like it is still un-clear. If you have questions please let me know.



    Sayed Ibrahim Hashimi

    You can download all the files at http://www.sedodream.com/content/binary/OutExample.zip


    (Edit: Updated MSBuild task usage to include Targets="Build")


    msbuild | Visual Studio Wednesday, November 21, 2007 6:29:57 AM (GMT Standard Time, UTC+00:00)  #     |
    Monday, November 19, 2007

    How would you enhance MSBuild?

    The MSBuild team is trying to prioritize their duties for the next release of MSBuild. Because of this they have asked for feedback on how their customers (us) would enhance MSBuild. They are doing this by distributing a virtual $100 across a possible 11 items. Their list actually ends in an item numbered 12, but there is no number 10. Here is a brief overview of their list of options.

    1. Higher Preformance
    2. VC Support
    3. Support for other project types
    4. Convert VS solution file to MSBuild format
    5. Better dependency tracking
    6. Distributed Build
    7. Inline Tasks – ie you write a script right in your MSBuild file instead of a compilied .NET task
    8. Scoping for items/properties – ie items/properties can exist in a defined scope
    9. Extensible functions – ie being able to add items like the Exists function
    11. MSBuild debugger
    12. MSBuild visualization

    Here is how I chose to distribute my $100.

    4   - $40
    6   - $10
    7   - $10
    11 - $30
    12 - $10

    About #4: In my experience, you have 2 scenarios that are the correct way to create build scripts for products. Those are

    1.      Create a custom MSBuild file that acts like a solution file

    2.      Use a solution file to drive the build process

    The only reason to go with 1 is because the solution file is not an actual MSBuild file, otherwise that wouldn’t even be an option. As for option 2, this is not ideal either because it is difficult to inject steps into how the solution build process works. All you can do is really extend what happens before/after the process.

    As for the debugger, this is a tool that I have actually wanted to write myself for a long time, but never had the time. If there was a debugger for MSBuild, I think that more people would begin to adopt MSBuild as well as get a much better understanding of how it works.

    It’s not often that teams from Microsoft ask for straight customer feature feedback, if you’re interested in future versions of MSBuild then you should definetly participate in this at: http://blogs.msdn.com/msbuild/archive/2007/11/17/how-would-you-spend-100-on-msbuild.aspx.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Monday, November 19, 2007 6:40:30 AM (GMT Standard Time, UTC+00:00)  #     |
    Tuesday, October 16, 2007

    Sedodream Relase: MSBuild Linq Tasks

    I’ve created a new release of MSBuild tasks, at www.codeplex.com/sedodream. This release includes 4 .NET 3.5 tasks built on Visual Studio B2. Those are all Linq MSBuild tasks. They are:

    Name

    Description

    CreateLinqCode

    Creates a Linq code file from a database.

    CreateLinqDbml

    Creates a Linq DBML file from a database.

    CreateLinqMap

    Creates a Linq Map file from a database.

    CreateDatabase

    Creates a database from an Linq DataContext which is contained in an assembly.


    The first three tasks simply wrap the SqlMetal command line utility. The last, CreateDatabse, will create a database from a Linq DataContext that is contained in an assembly. Right now there is little validation of the parameters passed, but I plan on adding additional validation. Also I will add more meaningful error messages, when invalid parameters are passed through.

    Below you’ll find an example of the CreateLinqCode task.

    <?xml version="1.0" encoding="utf-8"?>

    <Project ToolsVersion="3.5" DefaultTargets="Create" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <Import Project="$(MSBuildExtensionsPath)\Sedodream\Sedodream35.tasks"/>

      <Target Name="Create">

        <!-- sqlmetal /pluralize

                  /conn:"data source=(local);initial catalog=ibrtest;integrated security=SSPI;packet size=4096"

                  /timeout:15

                  /language:C#

                  /context:IbrTestDataContext

                  /code:ibrtest.cs

                  /views

                  /functions

                  /sprocs

                  /serialization:Unidirectional

                  /namespace:Sedodream.Linq.Test

                  -->

        <CreateLinqCode

          CodeFileName="ibrahimTest.cs"



          ConnectionString="data source=(local);initial catalog=ibrtest;integrated security=SSPI;packet size=4096"

          Timeout="15"

          Language="C#"

          ContextClassName="IbrTestDataContext"

          IncludeViews="true"

          IncludeSprocs="true"

          IncludeFunctions="true"

          TargetNamespace="Sedodream.Linq.Test"

          >

        </CreateLinqCode>

    </Target>

    </Project>

    Here is the CreateLinqDbml task usage.

    <?xml version="1.0" encoding="utf-8"?>

    <Project ToolsVersion="3.5" DefaultTargets="Create" xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <Import Project="$(MSBuildExtensionsPath)\Sedodream\Sedodream35.tasks"/>

      <Target Name="Create">

    <!-- sqlmetal /pluralize

                  /conn:"data source=(local);initial catalog=ibrtest;integrated security=SSPI;packet size=4096"

                  /timeout:15

                  /language:C#

                  /context:IbrTestDataContext

                  /dbml:../LinqObjects\ibrtest.dbml

                  /views

                  /functions

                  /sprocs

                  /serialization:Unidirectional

                  /namespace:Sedodream.Linq.Test

                  -->

        <CreateLinqDbml

          DbmlFileName="ibrahimTest.dbml"

          OutDir="."

          ConnectionString="data source=(local);initial catalog=ibrtest;integrated security=SSPI;packet size=4096"

          Timeout="15"

          Language="C#"

          ContextClassName="IbrTestDataContext"

          IncludeViews="true"

          IncludeSprocs="true"

          IncludeFunctions="true"

          TargetNamespace="Sedodream.Linq.Test"

          >

        </CreateLinqDbml>

      </Target>

    </Project>



    Please let me know if you have any questions/comments about these items.

    Sayed Ibrahim Hashimi

    msbuild | Sedodream MSBuild Project | Visual Studio Tuesday, October 16, 2007 12:50:48 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, June 27, 2007

    MSBuild log4net logger

    Ok, I know there are many MSBuild loggers available so why create a new one? Because for a while I’ve been thinking that it would be cool to have a logger that would transform an MSBuild log into a log4net log. This is because obviously log4net has many appenders and tools that you can use out of the box. For example if you wanted to put your logs into a database, then attach the AdoNetAppender. Because of this, and because I couldn’t already find one, I wrote one. You can find it on my Sedodream MSBuild project. This logger is called SedoLogger. I figured this would be a good name, in the case that later on I wanted to abstract out the specific logging mechanism behind it. I have just created a new release that contains all the necessary files. I have posted some usage information about this logger on the SedoLogger WiKi page. I’ll be posting some more details about this logger here in the near future.

    Sayed Ibrahim Hashimi

    msbuild | Sedodream MSBuild Project | Visual Studio Wednesday, June 27, 2007 6:09:10 AM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, April 27, 2007

    MSBuild Property & Item Overide Problems

    Hi,

    Someone contacted me regarding some issues he was having with respect to using the Web Deployment Project s and that was the inspiration for this post.
    There is an inherent problem with the way that Properties and Items are declared, created, overridden and used. There are a few problems those are:

    ·         PropertyGroup & ItemGroup elements are evaluated before any target executes.

    ·         Items are append only, meaning that you can’t delete items or any reference contained within them.

    We will now start by examining this issue. To simplify the issue I won’t use the Web Deployment Project files, or C# project files. But simpler files that let us focus on what is going on. Below is the file that represents the Microsoft.WebDeployment.targets file. This file is called Shared.proj.

    <Project

      xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <!--

      This represents the Microsoft.WebDeployments.targets file

      -->

      <PropertyGroup>

        <_AspNetCompilerVirtualPath>$(SourceWebVirtualPath)</_AspNetCompilerVirtualPath>

      </PropertyGroup>

      <ItemGroup>

        <_SourceWebPathItem Include="$(SourceWebPhysicalPath)"/>

      </ItemGroup>



      <Target Name="Build">

        <Message Text="Inside build shared.proj"/>

      </Target>



      <Target Name="PrintValues">

        <Message Text="SourceWebVirtualPath: $(SourceWebVirtualPath)"/>

        <Message Text="SourceWebPhysicalPath: $(SourceWebPhysicalPath)"/>



        <Message Text="_AspNetCompilerVirtualPath: $(_AspNetCompilerVirtualPath)"/>

        <Message Text="_SourceWebPathItem: @(_SourceWebPathItem)"/>

      </Target>



    </Project>

    Now let’s see the project file that represents the project that Visual Studio would create for you when you use the Web Deployments Template. My representative file is called Your.proj, it is shown below.

    <Project

      InitialTargets="PreBuild"

      DefaultTargets="PrintValues"

      xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <!-- This represents the .wdproj file -->



      <PropertyGroup>

        <SourceWebVirtualPath>WebPathItems</SourceWebVirtualPath>

        <SourceWebPhysicalPath>WebPathItems</SourceWebPhysicalPath>

      </PropertyGroup>



      <Target Name="PreBuild">

        <Message Text="Changing path to be 'OtherPath' instead of 'WebPathItems'"/>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebVirtualPath" TaskParameter="Value"/>

        </CreateProperty>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebPhysicalPath" TaskParameter="Value"/>

        </CreateProperty>

      </Target>



      <Import Project="Shared.proj"/>



    </Project>

    There are a couple of things to notice here, the first is that we are importing the Shared.proj file with the statement:

        <Import Project="Shared.proj"/>

    The other is that we are overriding the SourceWebVirtualPath and the SourceWebPhysicalPath values, in the PreBuild event which is on the InitialTargets list. Because of this we know that the PreBuild target will be executed before any target that is not on the InitialTargets list.

    Now going back to the Shared.proj file, we can see

      <PropertyGroup>

        <_AspNetCompilerVirtualPath>$(SourceWebVirtualPath)</_AspNetCompilerVirtualPath>

      </PropertyGroup>

      <ItemGroup>

        <_SourceWebPathItem Include="$(SourceWebPhysicalPath)"/>

      </ItemGroup>

    So from this we are creating a new property _AspNetCompilerVirtualPath based on the original SourceWebVirtualPath, and and item _SourceWebPathItem based on SourceWebPhysicalPath. These new properties and items are used throughout the Microsoft.WebDeployment.targets  file, and is a common practice amongst other .targets files. You’ll find something similar in the Microsoft.Commons.targets files. Now is where the problem arises, these new properties and items that have been declared in the PropertyGroup & ItemGroup, so they will be evaluated and assigned before the PreBuild target executes. Because of this you don’t really have a chance to actually override these values using any logic. The only (until you read further) way you can override them is to use static elements like PropertyGroup  and ItemGroup.

    You can see this is the case from the output of the PrintValues target below.

    Target PreBuild:
        Changing path to be 'OtherPath' instead of 'WebPathItems'

    Target PrintValues:
        SourceWebVirtualPath: OtherPath
        SourceWebPhysicalPath: OtherPath
        _AspNetCompilerVirtualPath: WebPathItems
        _SourceWebPathItem: WebPathItems

    Build succeeded.

    So how can we fix this? We need to be able to dynamically create properties & items and have them override static items? We can create a wrapper MSBuild file that does the logic to determine the correct values and the use the MSBuild Task. Have a look below at the file Fix.proj.





    <Project

      InitialTargets="PreBuild"

      DefaultTargets="Build"

      xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <!-- This represents the .wdproj file -->



      <PropertyGroup>

        <SourceWebVirtualPath>WebPathItems</SourceWebVirtualPath>

        <SourceWebPhysicalPath>WebPathItems</SourceWebPhysicalPath>

      </PropertyGroup>



      <Target Name="PreBuild">

        <Message Text="Changing path to be 'OtherPath' instead of 'WebPathItems'"/>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebVirtualPath" TaskParameter="Value"/>

        </CreateProperty>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebPhysicalPath" TaskParameter="Value"/>

        </CreateProperty>



        <Message Text="SourceWebVirtualPath: $(SourceWebVirtualPath)"/>

        <Message Text="SourceWebPhysicalPath: $(SourceWebPhysicalPath)"/>

      </Target>



      <Target Name="Build">

        <MSBuild Projects="Your.proj"

                 Properties="SourceWebVirtualPath=$(SourceWebVirtualPath);

                    SourceWebPhysicalPath=$(SourceWebPhysicalPath)"

                 Targets="PrintValues"

                 />

      </Target>



    </Project>

    Take a look at the highlighted portion, it simply calls MSBuild on the Your.proj fle. Here is the output when executing this file.

    Target PreBuild:
        Changing path to be 'OtherPath' instead of 'WebPathItems'
        SourceWebVirtualPath: OtherPath
        SourceWebPhysicalPath: OtherPath
    Target Build:

        __________________________________________________
        Project "C:\Data\Community\msbuild\WebDeploymentIssues\ASPNETix.proj" is building "C:\Data\Community\msbuild\WebDeploymentIssu\Sample\Your.proj" (PrintValues target(s)):

        Target PreBuild:
            Changing path to be 'OtherPath' instead of 'WebPathItems'
        Target PrintValues:
            SourceWebVirtualPath: OtherPath
            SourceWebPhysicalPath: OtherPath
            _AspNetCompilerVirtualPath: OtherPath
            _SourceWebPathItem: OtherPath

    Build succeeded.

    So you can see that all the desired values have been overridden. But having 2 files is really annoying, and in some cases you don’t really have this option. So because of this we need to find a solution that will modify the original file only. And here is that file, it is shown below its called YourFix.proj.

    <Project

      InitialTargets="PreBuild"

      DefaultTargets="PrintValues"

      xmlns="http://schemas.microsoft.com/developer/msbuild/2003">

      <!-- This represents the .wdproj file -->



      <PropertyGroup>

        <SourceWebVirtualPath>WebPathItems</SourceWebVirtualPath>

        <SourceWebPhysicalPath>WebPathItems</SourceWebPhysicalPath>

      </PropertyGroup>



      <Target Name="PreBuild">

        <Message Text="Changing path to be 'OtherPath' instead of 'WebPathItems'"/>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebVirtualPath" TaskParameter="Value"/>

        </CreateProperty>

        <CreateProperty Value="OtherPath">

          <Output PropertyName="SourceWebPhysicalPath" TaskParameter="Value"/>

        </CreateProperty>

      </Target>



      <PropertyGroup>

        <DoingFix>true</DoingFix>

      </PropertyGroup>



      <Import Project="Shared.proj"/>



      <!-- Here we conditionally override the PrintValues -->

      <Target Name="PrintValues" Condition="$(DoingFix)=='true'">

        <!-- Make a call to this file -->

        <MSBuild Projects="$(MSBuildProjectFullPath)"

                 Properties="DoingFix=false;

                  SourceWebVirtualPath=$(SourceWebVirtualPath);

                  SourceWebPhysicalPath=$(SourceWebPhysicalPath)"

                 Targets="PrintValues"

                 />

      </Target>

    </Project>

    In this approach we need to modify the behavior of the PrintValues target so we override it and have it call itself with the correct values. The MSBuild ProjectFullPath is an MSBuild Reserved Property, and it will return the full path of the current project file. The trick here is the conditional override of this target based on the DoingFix value. So we can see that the DoingFix property will default to true, so the PrintValues target will be overridden. But when the file is called back into with DoingFix=false it will not be overridden, and the PrintValues in Shared.proj will be used. In your use this target will most likely be Build. The drawback of the approach is that you’d have to overwrite each target that you are interested in. The other drawback is that it is confusing if you are not paying close attention to what this does. I posted something previously that used a similar technique read it if this interests you http://www.sedodream.com/PermaLink,guid,9c235811-3078-45e7-b122-6a239fb33fc0.aspx.

    Here is an outline of the files I have attached:

                    Shared.proj        => Represents a shared file (ie Miscrosoft.WebDeployments.targets)

                    Your.proj             => Represents your extension of the shared.proj file (ie SiteDeployment.wdproj)

                    Fix.proj                 => The wrapper that corrects the problems

                    YourFix.proj       => The real solution to this problem.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Friday, April 27, 2007 6:18:53 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, January 18, 2007

    MSBuild: Find Many Project References

    Ok, here is the challenge you have several project files that comprise a set of products. Now you want list every reference that each project file has. How do you do it? I came up with a pretty nifty way of doing it. If you look a project file for a managed project (I’ll be using C# projects for this example) you’ll see that you can see all the references listed in an Item named Reference. So there’s got to be a way to extract out that information for each project. I was thinking that it would be nice if each project had a target that would simply output that item. But that would involve changing each project to add the target to perform that. Which obviously is not an option. But what we can do is achieve the exact same thing, by using the Import element. Take a look at the simple targets file below:

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">



       <Import Project="$(ProjectFile)"/>



       <Target Name="GetReferences" Outputs ="@(ProjReferences)">

          <Message Text="Getting references for project $(ProjectFile)"/>

          <CreateItem Include="@(Reference)">

             <Output ItemName="ProjReferences" TaskParameter="Include"/>

          </CreateItem>

       </Target>



    </Project>

    What this will do is import an MSBuild project using the Import statement, this file is driven off of a property file. After that it will merge a new target GetReferences with the project declared in ProjectFile. Now we simply need a way to specify that ProjectFile. To achieve this we will actually change the above statements to include the condition Condition="$(ProjectFile)!=''". And we add the following statements to find all project files, enumerate references and write a file containing all of them.

    <!-- Project files to examine -->

    <ItemGroup>

       <ProjectFiles Include="**\*.csproj"/>

    </ItemGroup>

    <!-- File to save project references to -->

    <PropertyGroup>

       <RefFile>SolutionReferences.txt</RefFile>

    </PropertyGroup>



    <Target Name="SetupFindRef">

       <Delete Files="$(RefFile)"/>

       <WriteLinesToFile File="$(RefFile)" Lines="ProjectName%09Reference"/>

    </Target>



    <Target Name="FindReferences" Outputs="%(ProjectFiles.FullPath)" DependsOnTargets="SetupFindRef">

       <MSBuild Projects="$(MSBuildProjectFile)" Properties="ProjectFile=%(ProjectFiles.FullPath)" Targets="GetReferences">

          <Output ItemName="ProjReferences" TaskParameter="TargetOutputs"/>

       </MSBuild>



       <WriteLinesToFile File="$(RefFile)" Lines="%(ProjectFiles.FullPath)"/>

       <WriteLinesToFile File="$(RefFile)" Lines="@(ProjReferences->'%09%(Identity)')"/>

    </Target>



    If we execute the FindReferences target on this project file it will batch over each project file. It will then execute the same project file with the property ProjectFile defined, and execute the GetReferences target. So what is really happening is that we are effectively extending the existing MSBuild project file and injecting a new target to an existing  project file. Pretty nifty.

    Here is the entire project file so you can see the end result, also you can download it below.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003" DefaultTargets="FindReferences">

       <!-- Project files to examine -->

       <ItemGroup>

          <ProjectFiles Include="**\*.csproj"/>

       </ItemGroup>

       <!-- File to save project references to -->

       <PropertyGroup>

          <RefFile>SolutionReferences.txt</RefFile>

       </PropertyGroup>



       <Target Name="SetupFindRef">

          <Delete Files="$(RefFile)"/>

          <WriteLinesToFile File="$(RefFile)" Lines="ProjectName%09Reference"/>

       </Target>



       <Target Name="FindReferences" Outputs="%(ProjectFiles.FullPath)" DependsOnTargets="SetupFindRef">

          <MSBuild Projects="$(MSBuildProjectFile)" Properties="ProjectFile=%(ProjectFiles.FullPath)" Targets="GetReferences">

             <Output ItemName="ProjReferences" TaskParameter="TargetOutputs"/>

          </MSBuild>



          <WriteLinesToFile File="$(RefFile)" Lines="%(ProjectFiles.FullPath)"/>

          <WriteLinesToFile File="$(RefFile)" Lines="@(ProjReferences->'%09%(Identity)')"/>

       </Target>





       <Import Project="$(ProjectFile)" Condition="$(ProjectFile)!=''"/>

       <Target Name="GetReferences" Outputs ="@(ProjReferences)" Condition="$(ProjectFile)!=''">

          <Message Text="Getting references for project $(ProjectFile)"/>

          <CreateItem Include="@(Reference)">

             <Output ItemName="ProjReferences" TaskParameter="Include"/>

          </CreateItem>

       </Target>

    </Project>

    Here is what the result looks like (for the some of the Enterprise Library projects):

    ProjectName           Reference

    C:\TEMP\EnterpriseLibrary\src\Caching\Caching.csproj

       System

       System.configuration

       System.Configuration.Install

       System.Data

       System.Management

       System.Xml

    C:\TEMP\EnterpriseLibrary\src\Caching\Configuration\Design\Caching.Configuration.Design.csproj

       System

       System.configuration

       System.Data

       System.Design

       System.Drawing

       System.Windows.Forms

       System.XML

    C:\TEMP\EnterpriseLibrary\src\Caching\Cryptography\Caching.Cryptography.csproj

       System

       System.configuration

    C:\TEMP\EnterpriseLibrary\src\Caching\Cryptography\Configuration\Design\Caching.Cryptography.Configuration.Design.csproj

       System

       System.configuration

       System.Data

       System.Drawing

       System.Xml

    The above project file will actually generate a tab delimited file, so you can open it up in Excel and take a closer look.

     GetAllReferences.proj

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Thursday, January 18, 2007 7:05:31 AM (GMT Standard Time, UTC+00:00)  #     |
    Wednesday, November 22, 2006

    Sedodream MSBuild Project MSI

    Just wanted to let everyone know that my Sedodream MSBuild Project now has an MSI that can be downloaded. You can find that latest downloads at http://www.codeplex.com/Release/ProjectReleases.aspx?ProjectName=Sedodream. The installer will place all MSBuild tasks in the %Program Files%\MSBuild\Sedodream directory. In your MSBuild project files you  can refer to this location as $(MSBuildExtensionsPath)\Sedodream\.

    Here is a list of what is currently included in the project

    Tasks Included

    Name

    Description

    AddMetadata

    Allows you to add metadata to an item

    FindUnder

    Finds and returns all directories (empty or not) under a specified path

    GetDate

    Returns a string representation of the date in a specified format

    GetRegKey

    Returns the value of a registry key

    Move

    Task to move a file (or set of files)

    NUnitTask

    Task to run NUnit test cases as a part of the build process

    TempFile

    Returns the path to a new temporary file

    ReplaceInFile

    Can be used to replace specified text in a file.

    GetExternalIp

    Can be used to determine the external IP address of the executing machine

    GetInternalIp

    Can be used to determine all the Internal IP addresses of the executing machine

    Loggers Included

    Name

    Description

    EmailLogger

    An MSBuild logger capable of emailing the resulting log

    SimpleFileLogger

    A simple MSBuild file based logger

    XmlLogger

    An MSBuild logger which creates an Xml file

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio | Sedodream MSBuild Project Wednesday, November 22, 2006 3:14:56 AM (GMT Standard Time, UTC+00:00)  #     |
    Monday, November 13, 2006

    Add build steps

    There were a couple of posts in the MSBuild forum recently related to customizing the build process. The specific thread is, Forcing a Clean build. The question boils down to, "How do you force a clean each time I build?" The answer lies in adding the Clean target to the build targets dependency list. You can read details on how this works in my MSDN article Inside MSBuild.
    One of the participants asked me to post a complete solution of how to do this. So that response is this entry. I created a sample Windows Application that has the build process customized. I called this BeforeBuildEx, you can download all the files at the end of this entry. I modified the WindowsApplication1.csproj file and added the following lines:

    <PropertyGroup>

       <BuildDependsOn>

          Clean;

          MyBeforeBuild;

          $(BuildDependsOn);

          MyAfterBuild

       </BuildDependsOn>

    </PropertyGroup>



    <Target Name="MyBeforeBuild">

       <Message Text="This is before the build." Importance="high"/>

    </Target>



    <Target Name="MyAfterBuild">

       <Message Text="This is after the build." Importance="high"/>

    </Target>

    The list of targets that must be executed for a build is contained in the BuildDependsOn list. So if you change that list, you change to build process. If you want to add a target before the build process, add that target to the begining of the list. In the above statement, I'm actually extending the previous list by adding my targets. I add 2 targets before and 1 after the already existing definiton for BuildDependsOn. Much more detail about this in my article. The snippet above was inserted after the statement

    <Import Project="$(MSBuildBinPath)\Microsoft.CSharp.targets" />

    This is very important, otherwise your customizations may be overwritten. Now if you build this you will see that the Clean target is executed when the application is built. If you want to see this in Visual Studio you have to increase the verbosity of the MSBuild output that is shown on the Output window. Do this by: Tools->Options->Projects and Solutions->Build and Run and set the value for MSBuild project build output verbosity to atleast Normal. The link to the zip file is below. In some cases this could cause some problems for Visual Studio.

    BeforeBuildEx.zip

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Monday, November 13, 2006 4:11:06 AM (GMT Standard Time, UTC+00:00)  #     |
    Tuesday, August 29, 2006

    MSBuild Batching 2

    A twist on the previous entry. Here’s a very similar, but different scenario. You have a set of files, that you want to push to a set of folders. But you have to “discover” these folders. In this scenario there are really 2 different situations you can be in.

    1.       Each folder contains a file that you are able to identify by file name

    2.       Each folder contains no files, but you are able to identify the folder by its name

    For 2) you’ll have to rely on a custom task to get locate these folders. This is because if the folder is empty then you are not able to put these in an Item the normal way. I’ve previously written a task FindUnder that you can use for this purpose. You can find this task, and a handful of others at http://www.codeplex.com/Wiki/View.aspx?ProjectName=Sedodream. Let’s go over scenario 2 because I think it’s a little more straight forward.

    Here is the directory structure that you have to work with:

       AssemblyInfo.cs

       DeploySample.proj

       Other1.cs

       Other2.cs

    ├───Deploy

       ├───five.control

       ├───four.control

       ├───one.control

       ├───six.control

       ├───six.something

       ├───three.control

       ├───three.something

       └───two.control

    In this example the folders that you want to copy into end with .control, and the files you want to copy include AssemblyInfo.cs, Other1.cs and Other2.cs. In this situation we want to find all folders under Deploy that end with control. So our search pattern will be *control under the Deploy folder. Here’s how we find those folders using the FindUnder task, and copy the files into them.

       <PropertyGroup>

          <DeployRoot>Deploy</DeployRoot>

          <SearchPath>*.control</SearchPath>

       </PropertyGroup>

       <ItemGroup>

          <FilesToCopy Include="AssemblyInfo.cs;Other1.cs;Other2.cs"/>

       </ItemGroup>

       <Target Name="Deploy">

          <Copy SourceFiles="" DestinationFolder=""/>

          <!-- Find all the folders we need to place the AssemblyInfo.cs file in -->

          <FindUnder Path="$(DeployRoot)" FindDirectories="true" SearchPattern="$(SearchPath)">

             <Output ItemName="DeployFolders" TaskParameter="FoundItems"/>

          </FindUnder>



          <Message Text="Found items: @(DeployFolders,'%0d%0a')" Importance="high"/>

          <Copy SourceFiles="@(FilesToCopy)" DestinationFolder="%(DeployFolders.FullPath)"/>

       </Target>

    Let’s talk about the Copy task above. This shows how we can copy a set of folders to a set of different folders. This is possible through batching which was discussed in more detail in the previous post. As you use batching keep in mind that batching isn’t limited to custom meta-data. But can also be used with Well-known item metadata. That is what we are doing in this example.

    Now let’s see how can we handle situation 1). To review, this is the situation that we have files in a set of directories that we can identify. In this example let’s say that file is named app.config. So we want to find all folders under a given location that have a file named app.config inside of it. So here is your directory structure

       AssemblyInfo.cs

       DeploySample.proj

       Other1.cs

       Other2.cs

    └───Deploy2

          ├───five.control

                 app.config

          ├───four.control

                 app.config

          ├───one.control

                 app.config

          ├───six.control

                 app.config

          ├───six.something

          ├───three.control

                 app.config

          ├───three.something

          └───two.control

                app.config

    So the result should actually be the same as the previous example. This is how to achieve that.

       <PropertyGroup>

          <DeployRoot2>Deploy2</DeployRoot2>

       </PropertyGroup>



       <ItemGroup>

          <KeyFiles Include=".\$(Deploy2)\**\app.config"/>

       </ItemGroup>



       <Target Name="Deploy2">

          <Message Text="Folders to deploy to:%0d%0a@(KeyFiles->'%(RecursiveDir)','%0d%0a')"/>



          <!-- Now copy each file to each destination -->

          <Copy SourceFiles="@(FilesToCopy)" DestinationFolder=".\%(KeyFiles.RecursiveDir)"/>

       </Target>



    So the in this example I’m using the KeyFiles item to determine which folders to copy all the files to. From the Deploy2 target you can see that I’m using batching to copy all the FilesToCopy into each of the locations determined by the KeyFiles item. The directory that contains each KeyFile is determined by the RecursiveDir well-known meta-data value.



    You can download the entire sample at: www.sedodream.com/content/binary/BatchingSample.zip

    Or you can have a look at the project file at:  www.sedodream.com/content/binary/DeploySample.proj.txt



    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Tuesday, August 29, 2006 3:17:46 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, August 15, 2006

    MSBuild batching

    Today someone was telling me about a co-worker who was having issues with MSBuild. He told me that he was trying to copy a set of files to a set of different servers. But the issue was that he didn’t know how to achieve this without performing multiple Copy task invocations. I told him that he could achieve this using MSBuild Batching. Batching is a process of performing a task (or target) on a set of items (batches) at a time. A batch can also include a single item. So in this scenario we need to perform the copy one time for each server that he wanted to deploy to. I’ve created a simple msbuild file which demonstrates this in two different ways. The first way uses task batching, which can bee seen in the Test target. And the other uses Target batching which can be seen in the DoItCore target. I've also created a clean target, which has nothing to do with batching.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003" DefaultTargets="Test">



          <ItemGroup>

                <SourceFiles Include="*.txt"/>

                <Dest Include="One;Two;Three;Four;Five"/>

          </ItemGroup>



          <Target Name="Test">

                <Copy SourceFiles ="@(SourceFiles)" DestinationFolder="%(Dest.FullPath)"/>

                <Message Text="Fullpath: %(Dest.FullPath)"/>

          </Target>



          <!-- These targets demonstrate target batching -->

          <Target Name="DoIt" DependsOnTargets="DoItCore"/>

          <Target Name="DoItCore" Inputs="@(SourceFiles)" Outputs="%(Dest.FullPath)">

                <Copy SourceFiles="@(SourceFiles)" DestinationFolder="%(Dest.FullPath)"/>

          </Target>



          <!-- This will clean up the files -->

          <Target Name="Clean">

                <CreateItem Include="%(Dest.FullPath)\**\*">

                      <Output ItemName="FilesToDelete" TaskParameter="Include"/>

                </CreateItem>

                <Delete Files="@(FilesToDelete)"/>

          </Target>

    </Project>

    Batching is an advanced topic of MSBuild, and is defintely neglected. I have to admit I’m guilty of not writing about it enough myself. There are some good batching resources, they are listed below.

    MSBuild Batching

    How To : Batch Targets with Item Metadata

    Batching Brainteaser Explained

    Channel 9 : Batching Examples

    Channel 9 : How does MSBuild’s Batching Algorigth Work?



    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Tuesday, August 15, 2006 4:59:32 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, August 09, 2006

    MSDN Library free to download!

    In case you haven't already heard the MSDN Library is now free to download! You can download the May 2006 version at: http://www.microsoft.com/downloads/details.aspx?FamilyId=373930CB-A3D7-4EA5-B421-DD6818DC7C41&displaylang=en

    Previously you could only get the MSDN Library if you were an MSDN Subscriber. I think its great that Microsoft made the MSDN Library free to download. It's a great resource and contains all kinds of goodies for .NET developers.

    Sayed Ibrahim Hashimi

    Visual Studio Wednesday, August 09, 2006 5:32:45 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, July 25, 2006

    MSBuild book content online

    Recently a chapter from my book Deploying .NET Applications: Learning MSBuild and ClickOnce has been posted. You can read the sample chapter MSBuild By Example. Here is the TOC for that chapter.

    MSBuild: By Example

    Introducing Well-Known Metadata

    Formatting Your Output

    Editing MSBuild Files with IntelliSense

    Integrating MSBuild into Visual Studio

    Introducing Custom Metadata

    Understanding the Difference Between @ and %

    Using Environment Variables in Your Project

    Reusing MSBuild Project Elements

    Dealing with MSBuild Errors

    Summary

    Thanks to the guys at Apress and C# Online for making this chapter available online for everyone to have a look at!

    Sayed Ibrahim Hashimi





    msbuild | Visual Studio Tuesday, July 25, 2006 5:31:32 AM (GMT Daylight Time, UTC+01:00)  #     |
    Tuesday, July 18, 2006

    MSBuild content available on CodePlex

    I've created a project on CodePlex to hold all of the MSBuild tasks/loggers and what not from my book and my MSDN article Inside MSBuild. The project home page is at Sedodream MSBuild CodePlex project. The idea is that I'll keep all of the MSBuild related material that I discuss here there as well. If you have content that you'd like to post there thats great too.
    Here is the current list of what is available there:

    Tasks Included

    Name

    Description

    AddMetadata

    Allows you to add metadata to an item

    FindUnder

    Finds and returns all directories (empty or not) under a specified path

    GetDate

    Returns a string representation of the date in a specified format

    GetRegKey

    Returns the value of a registry key

    Move

    Task to move a file (or set of files)

    NUnitTask

    Task to run NUnit test cases as a part of the build process

    TempFile

    Returns the path to a new temporary file

    Loggers Included

    Name

    Description

    EmailLogger

    An MSBuild logger capable of emailing the resulting log

    SimpleFileLogger

    A simple MSBuild file based logger

    XmlLogger

    An MSBuild logger which creates an Xml file

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Tuesday, July 18, 2006 5:47:05 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, June 15, 2006

    MSBuild Visual Editor

    A few days ago I received an email about an MSBuild visual editor! This was something that I was interested in doing a while ago, but never got around to doing it. This tool is called MSBuild Sidekick, and you can download it for free from http://www.attrice.info/msbuild/index.htm. I have downloaded it and played around with it. I think it’s a good tool for people who are getting started with MSBuild, but for those who use MSBuild on a regular basis I don’t think it can replace the productivity that is achieved with Intellisense. They have an interesting way of representing the build file visually, and after some time if the right extensions are added it may be a tool that I’d use over Visual Studio to edit my MSBuild files. One of the challenges of representing a build file is that you have to be aware of where your new declarations are being placed. For instance if you have two properties defined, lets say Property1 and Property2. If Property2 depends on Property1 then you have to make sure that it is declared after Property1. As far as I could tell there was no way to achieve this without viewing the source of the project file through the tool.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Thursday, June 15, 2006 6:14:45 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, June 14, 2006

    MSBuild: Pre/Post build event funniness

    In previous versions of the Visual Studio the build customizations were basically limited to a PreBuildEvent and a PostBuildEvent. Now we have MSBuild which allows for many very specific and complex build customizations. But Microsoft obvioiusly must continue to support the Pre/Post build event. It is something that already exists, many people are familiar with it, and its very simple. Let’s see how this is implemented within MSBuild. If you add a Pre or Post build event from Visual Studio, then examine yore project file you’ll find something like the following declared.



      <PropertyGroup>

        <PostBuildEvent>echo 'This is the post build event!'</PostBuildEvent>

      </PropertyGroup>



    So these events are actually simple properties that will be executed when the time is right. What does this mean for you? Now lets talk about what’s funny about this. When MSBuild loads your project file it will load all of the properties contained in PropertyGroup elements, followed by that your items will be evaluated. What this means for the Pre/Post build event is that you are able to access properties that have been declared in PropertyGroup element before the Pre/Post build event declaration. After this evaluation is made the value for the Pre/Post build event will not change! What this equates to is that you are able to use properties such as OutDir or AssemblyName, but you’ll never be able to access properties that are created from tasks contained in other targets! If you need to access properties that have been created by other targets then you’ll have to extend your build process outside of the Pre/Post build event. This is outlined in my MSDN article Inside MSBuild in the Extending the Build Process section.

    This entry was inspired by a post on the MSDN MSBuild forum.



    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Wednesday, June 14, 2006 5:52:03 AM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, June 09, 2006

    MSBuild Xml Logger

    If you look around the net you'll find a few different Xml loggers for MSBuild. When I was writing my book I decided to write my own Xml Logger for a few different reasons. The source for the Xml logger that I wrote is available at apress.com. I'm currently in the process of trying to get some shared space for me to place my tasks and loggers that I've written for everyone to have a look at. Once I get that squared away I'll make sure to write an entry about it. In the mean time let's talk about my Xml logger. What is different about my Xml logger versus some others that you may find? When I was looking around for one, I noticed that the ones that I found didn't support building solution files very well. So that was a deficiency that I wasn't willing to sacrifice with. Besides that, I noticed that none of them had an append options as most file based loggers do. So I added that to my Xml logger. I think this is a good option if you are performing a nightly ( or continuous ) build. That way you have one place to go to each time you want to see how your build progressed. However this xml file can get quite large if your build is spanning many projects.
    At the bottom of this blog you can download the dll for this logger (Contained in a zip file). The source will be made available soon. There are 4 logger arguments:


    Name

    Description

    Append

    True/false If true then if a log file exists then it will be append to, otherwise any existing log file will be replaced.

    Logfile

    Name of the log file to write to

    Showsummary

    True/false if true then a summary will be contained in the xml file for errors and warnings.

    Verbosity

    The verbosity level of the logger. Same as msbuild.exe values see MSBuild Command Line Reference


       Here is some sample output:

    <MSBuild>

      <Build Started="6/9/2006 1:09:51 AM" Verbosity="Detailed"

    Finished="6/9/2006 1:09:56 AM" Succeeded="False">

        <Message>Build started.</Message>

        <Project Name="C:\Data\Dreamcatcher_NET\Dreamcatcher\Dreamcatcher.sln"

    Message="Project &quot;Dreamcatcher.sln&quot; (Rebuild target(s)):" \

    Started="6/9/2006 1:09:51 AM" Finished="6/9/2006 1:09:56 AM">

          <Target Started="6/9/2006 1:09:51 AM" Name="ValidateSolutionConfiguration"

    Message="Target &quot;ValidateSolutionConfiguration&quot; in project &quot;Dreamcatcher.sln&quot;" Finished="6/9/2006 1:09:51 AM" Succeeded="True">

            <Task Started="6/9/2006 1:09:51 AM" Name="Message" Finished="6/9/2006 1:09:51 AM" />

          </Target>

    <MSBuild>



    Here is what the summary section looks like:

        <Warnings>

          <Warning Code="CS0162" Subcategory="">

            <Message>Controls\DreamView.cs(450,6): warning CS0162: Unreachable code detected</Message>

          </Warning>

        </Warnings>

        <Errors>

          <Error File="Controls\DreamView.cs" Code="CS1026" Subcategory="">

            <Message>Controls\DreamView.cs(459,44): error CS1026: ) expected</Message>

            <Location Line="459" ColumnNumber="44" />

          </Error>

          <Error File="Controls\DreamView.cs" Code="CS1002" Subcategory="">

            <Message>Controls\DreamView.cs(459,45): error CS1002: ; expected</Message>

            <Location Line="459" ColumnNumber="45" />

          </Error>

          <Error File="Controls\DreamView.cs" Code="CS1525" Subcategory="">

            <Message>Controls\DreamView.cs(459,45): error CS1525: Invalid expression term ')'</Message>

            <Location Line="459" ColumnNumber="45" />

          </Error>

          <Error File="Controls\DreamView.cs" Code="CS1002" Subcategory="">

            <Message>Controls\DreamView.cs(459,46): error CS1002: ; expected</Message>

            <Location Line="459" ColumnNumber="46" />

          </Error>

        </Errors>

    The syntax to use this logger at the command prompt is:

    msbuild.exe /l:XmlLogger,PATH_TO_ASSEMBLY\Sedodream.MSBuild.Loggers.dll;logfile=build.xml;verbosity=detailed;append=true;showsummary=true

    There is no required parameters the defaults are:

    Sedodream.MSBuild.Loggers.zip (binaries 9.77 KB)


    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Friday, June 09, 2006 6:34:17 AM (GMT Daylight Time, UTC+01:00)  #     |
    Sunday, June 04, 2006

    C# vs Java

    Ok, there's several posts about whats good/bad about both of these languages, this isn't one of those. At the end of the day it doesn't matter which technology is the best, but which ones are going to employ you. About a year ago, I think there were many more Java jobs here in Jacksonville (FL) then there were C# (.NET) jobs. I've noticed that there has been an increasing need for C# developers here, can't really say about the Java positions though. Recently I've been playing around with the blog search engine technorati.com, they have some really cool features. If you've never been there you should give it a shot. One of the features is to chart the number of blog entries over a period of time, based on keywords. To view the graph of MSBuild related blogs click on the link below

    http://technorati.com/chart/%22MSBuild%22#taglink

    I decided to compare the results of a search of "C#" and "Java", and I was really surprised to see the results. Below you can see the images that I saw. Note: These images are static and not updating.

    From the technorati.com site it stated that there was 668,373 Java related posts and 17,100,527 C# posts! That is an incredible difference. There could be a few reasons for the difference:

    1. Java people arn't blogging as much
    2. Java people arn't registering with technorati.com as much as the C# folk
    3. There is something wrong with the technorati.com processor

    Since this is a simple keyword search I think we can safely assume that (3) is not the culprit. I think its really a combinition of (1) and (2). Another aspect there are many Java related blog entries that don't actually have the word Java in it. But I'm sure the same goes for C#. Previously when I was doing mostly Java work, I thought one of the cool things about Java was the community effort. With the open-source side and all. I thought that C# (.NET) would lack this for sure. But now that I know better, I know that it certainly is not like that. I think the community effort for C# (.NET) is just as strong, if not stronger, then the Java side.

    I'm not sure what the significance these number have, but it certainly does make be happy to be in the C# camp. :)

    To get the live chart for C# visit: http://technorati.com/chart/%22C%23%22#taglink
    To get the live chart for Java visti: http://technorati.com/chart/%22Java%22#taglink

    Sayed Ibrahim Hashimi

    Java | msbuild | Visual Studio Sunday, June 04, 2006 7:39:13 AM (GMT Daylight Time, UTC+01:00)  #     |
    Saturday, June 03, 2006

    Visual Studio 2005 for .NET 1.1 development

    Frequently I hear people asking "How can we use Visual Studio 2005 for 1.1 development". If you are writing managed code (C#,J#, or VB.NET) then you are in luck. There is a toolkit that was released from the guys at Microsoft that can do this for you. Its called MSBee (MSBuild Everett Edition). You can download this toolkit at Codeplex. The creator of MSBee blogs about it at: http://blogs.msdn.com/clichten/default.aspx

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Saturday, June 03, 2006 7:38:13 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, May 10, 2006

    MSBuild: Build several projects

    I received this email from a reader of my MSBuild MSDN Article, here is his question:

    I have multiple projects in multiple directories on my machine, I need to compile all of those projects and copy the resulting DLLs into my application folder which id different from the projects. Can i do all this in one MSBuild file? Most the MSBuild file samples i find work only on a single project and assume that the build file is in the same directory as the .CS files.

    To answer this question you can create an MSBuild project file which uses the MSBuild task to build other project files. By using this you can extract out the files that were built during the process and place them into an item to be copied to the location of your choice. To demonstrate this I have created the following directory structure:

    ├BuildSeveralExample

       ├───App1

          └───WindowsApplication1

              └───Properties

       ├───App2

          ├───ClassLibrary1

             └───Properties

          └───ConsoleApplication1

              └───Properties

       └───Deploy



    The App1 and App2 folders each represent a product that is to be built. App1 contains a C# Win Forms project and App2 contains a C# Class Library and a C# Console App. The Deploy folder is the location that we would like to copy all of the output files to. In the BuildSeveralExample folder I have created a projects file, BuildAll.proj, which can be used to fulfill this need.

    The first thing we need to do is to have a way to locate all of the project files, in my solution I created an Item and included all of the project files as such:
      <ItemGroup>

        <ProjectsToBuild Include="**\*proj" Exclude="$(MSBuildProjectFile)"/>

      </ItemGroup>

    I include all project files in the current directory or any subdirectory, with the exception of the current project file. The MSBuildProjectFile is an MSBuild Reserved property, for a complete list see:  http://msdn2.microsoft.com/en-us/library/ms164309.aspx.

    In your situation you may need to specify what files to include and exclude, to do this you can simply enter their locations separated with a semi-colon. Now that we have all the project files we’d like to build we need to actually build them. Do this by:

      <PropertyGroup>

        <Configuration>Release</Configuration>

      </PropertyGroup>



      <Target Name="CoreBuild">

        <MSBuild Projects ="@(ProjectsToBuild)"

                 ContinueOnError ="false"

                 Properties="Configuration=$(Configuration)">

            <Output ItemName="OutputFiles" TaskParameter="TargetOutputs"/>

        </MSBuild>

      </Target>



    This is using the MSBuild Task to each of the project files. Also note the use of the Output element here, the MSBuild Task has an output of TargetOutputs which contains a list of files which were produced by the project files built. These files are placed in the OutputFiles item. Since we didn’t specify a target to be executed on each project file, the default target will be executed. This is how Visual Studio builds your project files as well. By using the MSBuild task we can also specify properties to be passed to the project file(s) in the Properties attribute. If you need to pass different properties for different project files, then you may have to call the MSBuild Task more than once.

    Now all we have to do is copy these files over to another location. This is achieved like:



      <PropertyGroup>

        <DestFolder>Deploy\</DestFolder>

      </PropertyGroup>



      <Target Name="CopyFiles">

        <Copy SourceFiles="@(OutputFiles)"

              DestinationFiles="@(OutputFiles->'$(DestFolder)%(RecursiveDir)%(Filename)%(Extension)')" />

      </Target>

    The location to copy the files is specified in the DestFolder property shown above.

    As well as performing these actions, we’d also like to create a fresh build when this process is invoked. To do this we can either call the Rebuild target on the project files or call Clean before we build them. I prefer the second approach, but both are equally good. It also serves for a better demonstration for me to implement the second approach.

    To clean the projects all we have to do is call the Clean target on each of the project files. I have written about this in more detail in my previous entry Clean many projects and Extending the Clean. As well as that we have to remove any files that have been created by a previous invocation of this process, have a look at my clean target:

      <!--

      This target can be used to clean all of the projects before you build them.

      It will also delete any dll & exe files located in the the Deploy folder. This could be accomplished

      much better than this, but this is quick and easy.

      -->

      <Target Name="CleanAll">

        <!-- Delete any files this process may have created from a previous execution -->

        <CreateItem Include="$(DestFolder)\**\*exe;$(DestFolder)\**\*dll">

          <Output ItemName="GeneratedFiles" TaskParameter="Include"/>

        </CreateItem>

        <Delete Files="@(GeneratedFiles)"/>

        <MSBuild Projects="@(ProjectsToBuild)" Targets="Clean" Properties="Configuration=$(Configuration);"/>

      </Target>

    To tie it all together I’ve created a BuildAll target which is responsible for managing all of this. Here it is:

      <PropertyGroup>

        <BuildAllDependsOn>CleanAll;CoreBuild;CopyFiles</BuildAllDependsOn>

      </PropertyGroup>

      <Target Name="BuildAll" DependsOnTargets="$(BuildAllDependsOn)"/>

    I took the Visual Studio approach and defined targets to perform individual steps, created one target to call them in the correct order by using a depends list derived from a property. This is a good approach because this depends on list can be modified outside of this project file to inject other required steps. For more detailed info on that see my other entry Extending the clean.

    To see this in action you have to execute the BuildAll target on the BuildAll.proj file. I’ve made the project file available as well as my sample applications that go along with it. The BuildSeveralExample.zip file contains all the necessary files.



    BuildAll.proj (Link fixed)

    BuildSeveralExample.zip (25.17 KB)



    Sayed Ibrahim Hashimi



    msbuild | Visual Studio | Windows Forms Wednesday, May 10, 2006 6:39:05 AM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, May 03, 2006

    MSBuild fun part 1: Copying files

    This is the beginning of a new series of blogs that I plan on writing. Its called ‘MSBuild Fun’, the idea is that I’ll discuss some examples of how you might use MSBuild, outside of building applications. MSBuild is a tool that certainly is geared toward building applications, but is not limited to that. Knowledge of MSBuild can help you with some small things that come up quite often.

    In this example we will consider a relatively simple task, copying a set of files from one location to another. Let’s say that you would like to locate all image files contained in a particular location and copy those files to another. There are a few options; you can use the Windows Explorer to search for all of the image files, and copy-paste them to the other location. There are many problems associated with this approach:

    Another option is to use the xcopy command from the command prompt. This is a good method to employ to solve the problems associated wit the previous approach. Using this approach we can continue on error,  and preserve the directory hierarchy.  We can also exclude files from being copied. If you are to perform this task many times that you can simply insert the call into a .bat file to preserve the command.
    The approach we will use here is to use MSBuild
    Copy task to copy the files from the source to the destination. It solves all the problems associated with the first approach, and throws in a few bonuses. Those are:

    From a performance perspective the xcopy and MSBuild approach are pretty much equivalent, so that is not a factor. Now lets have a look at this in action.

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003" DefaultTargets="CopyFiles">

        <ItemGroup>

          <FilesToCopy Include="**\*.doc;**\*.txt"

                       Exclude="**\*trash*"/>

        </ItemGroup>



        <PropertyGroup>

          <Dest>Dest2</Dest>

        </PropertyGroup>



        <Target Name="CopyFiles">

          <Copy SourceFiles="@(FilesToCopy)"

                DestinationFiles="@(FilesToCopy->'$(Dest)\%(RecursiveDir)\%(Filename)%(Extension)')"

                ContinueOnError="true"/>

        </Target>

    </Project>

    This simple MSBuild project file will copy all Word Documents and text files that don’t contain trash in the filename to another location maintaining the directory hierarchy. As you can see here, in the FilesToCopy item declaration, I’m using the include attribute to include a list of files to be copied, and the exclude attribute to exclude a list of files from being copied. You can place complex wildcard expressions in these attributes to select only the files you are truly interested in.





    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Wednesday, May 03, 2006 6:02:18 AM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, April 21, 2006

    My MSDN Article

    In the June 06 issue of the MSDN magazine you'll find an article that I wrote titled "Inside MSBuild: Compile Apps Your Way With Custom Tasks For The Microsoft Build Engine". As far as I know this will be the first article in print for the release version of MSBuild. Before I wrote this article I noticed a need, that was there was no one good resource for people to go to to learn all the key things they need to really get going with MSBuild. I think this article really does meet that need decently well. The only large topic that wasn't covered in the article is writing custom loggers. There are a few reasons for this; limited number of words, most users won't be interested in writing custom loggers and there is a lot of material about writing custom loggers available. If you are interested in writing a custom logger, I've got examples on this blog and here are a few other places you can visit:
    http://msdn2.microsoft.com/en-us/library/ms171471.aspx
    http://blogs.msdn.com/msbuild/archive/2005/10/10/479223.aspx

    Along with these in my book I present a custom XML logger. If you read the article I welcom your feedback.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Friday, April 21, 2006 3:13:06 PM (GMT Daylight Time, UTC+01:00)  #     |
    Wednesday, April 05, 2006

    Team Build + MSBuild Properties

    If you are using Team Foundation Server as your SCM tool, I hope you're taking advantage of using the Team Build tool to create re-producable public builds for your projects. Very cool, and very useful, especially for those Enterprise applications. As you use Team Build you'll need to make changes to how your build process is executed. You can make the customizations in the TFSBuild.proj file. This is the file that will drive your team build. In this file there are many properties declared that are generated by the New Build Type Creation Wizard. These properties are contained in the first PropertyGroup element in that file. Some of these properties include; Description, DropLocation,BuildDirectoryPath,... which are used internally by Team Build to setup the build. Of course Team Build uses MSBuild to actually execute the build, but some things need to happen before/after MSBuild gets involved. For instance creating the Build report, which require those values. In the ideal world you'd expect for those values to be gathered using the MSBuild Object Model, but this is not the case. Team Build is extracting those values as they are declared.
    There has been a few posts about this particular problem on the MSBuild MSDN Forum. Those posts are at:
    Post: Property Evaluation Order (beta 3)
    Properties in properties
    In the post Property Evaluation Order (beta 3) I provide a workaround for most situations, but its not always perfect. Here it is for you to see:

    It seems like Team build is not using the msbuild object model to get those evaluated properties, but instead are simply extracting the text value from those property declarations.

    I tried to overwirte it in different places in the project file as well, with no luck. It always took the first declaration. I'm guessing that the property is not able to be overwritten because it is passed in as a command line parameter to msbuild.exe by team build. But there is a workaround that solves some of the issues. In your TFSBuild.proj file, modify the DropLocation to one that doesn't use any properties and insert the following towards the bottom:

      <PropertyGroup>

        <RootProjectFolder>ProjectX</RootProjectFolder>



        <DropBuildDependsOn>

          FixDropLocation;

          $(DropBuildDependsOn);

        </DropBuildDependsOn>

      </PropertyGroup>



      <Target Name="FixDropLocation">

        <CreateProperty Value="$(DropLocation)\$(RootProjectFolder)">

          <Output TaskParameter="Value" PropertyName="DropLocation"/>

        </CreateProperty>

        <Message Text="Drop loc: $(DropLocation)" Importance="high"/>

      </Target>

    This prepends the FixDropLocation to the DropBuildDependsOn list of targets, so it will be executed before the DropBuild target. This cause your project drop files to be dropped in the location tat you want. This is able to overwrite the DropLocation property becuase we are using the CreateProperty task to overwrite this instead of the normal property declaration.

    This is not however a perfect solution, because your build log will always be located in the DropLocation that was originally declared (the one w/o the property embedded within it). And in the Team build type history the drop location will also have this location as well. But it does place the files where you want them :)

    Unfortunately it looks like the DropLocation that is given to TFS is happening outside the scope of MSBuild so I'm not sure you have a lot of options. You can't even pass this as a command line parameter to the tfsbuild.exe utility either. Let me know if this  is not clear.


    Sayed Ibrahim Hashimi


    msbuild | Team Build | TFS | Visual Studio Wednesday, April 05, 2006 8:09:52 AM (GMT Daylight Time, UTC+01:00)  #     |
    Friday, March 31, 2006

    VS Service Packs!

    In case you haven't already heard a service pack will be released for both VS 2003 & VS 2005 this year! SP1 for VS 2003 is scheduled to ship during the second quarter, and SP1 for VS 2005 in the third. You can read more about this at: http://msdn.microsoft.com/vstudio/support/servicing/. I think its kind of interesting that VS2003 didn't have a service pack for 3 years, yet 2005 is having one not even 1 year later. Perhaps because of all the new features that were shipped with this version, however VS 2003 shipped with many new features as well. Since MSBuild is technically a part of the .NET Redistributable, I'm not sure if the service packs will impact anything related to MSBuild. If I find out more I'll be sure to post more.

    Sayed Ibrahim Hashimi

    Visual Studio Friday, March 31, 2006 7:07:45 AM (GMT Daylight Time, UTC+01:00)  #     |
    Thursday, March 30, 2006

    MSBuild Tigris tasks

    Previoiusly I wrote about the Microsoft SDC Tasks library, there is another great resource for MSBuild tasks. This is the MSBuild Tigris Tasks project. This is an open source project, so you can submit your tasks to this library as well. Tigris.org is known for their Source Control Management (SCM) tool, Subversion. I've used Subversion previously and was pleased with it, but my favorite is Team Foundation Server :) If you're using Subversion as your source control you'll be glad to find many task for accessing your repository. From the project's site here is a list of the MSBuild tasks that are either completed or currently under development.

    Task

    Description

    AppPoolController*

    Allows control for an app pool on a local or remote machine with IIS installed.

    AppPoolCreate*

    Creates a new application pool on a local or remote machine.

    AppPoolDelete*

    Deletes an existing application pool on a local or remote machine.

    AssemblyInfo

    Generates an AssemblyInfo file using the attributes given.

    Attrib*

    Changes the attributes of files and/or directories

    FileUpdate*

    Replace text in file(s) using a Regular Expression.

    FtpUpload

    Uploads a file using File Transfer Protocol (FTP).

    FxCop*

    Uses FxCop to analyze managed code.

    Mail

    Sends an email message.

    Math.Add

    Add numbers.

    Math.Divide

    Divide numbers.

    Math.Multiple

    Multiple numbers.

    Math.Subtract

    Subtract numbers.

    Move*

    Moves files on the filesystem to a new location.

    NDoc

    Runs NDoc to create documentation.

    NUnit

    Runs tests using the NUnit.

    RegistryRead

    Reads a value from the Registry.

    RegistryWrite

    Writes a value to the Registry.

    Script*

    Executes code contained within the task.

    ServiceController*

    Task that can control a Windows service.

    ServiceQuery*

    Task that can determine the status of a service.

    Sleep*

    A task for sleeping for a specified period of time.

    SqlExecute*

    Executes a SQL command

    SvnCheckout

    Checkout files from Subversion

    SvnClient

    Subversion Client

    SvnCommit

    Commit files to Subversion

    SvnExport

    Export files from Subversion

    SvnInfo*

    Get Subversion information for a file or directory.

    SvnUpdate

    Update files from Subversion

    SvnVersion

    Get Subversion revision number of a local copy

    TaskSchema*

    Generates a XSD schema of the MSBuild tasks in an assembly.

    Time*

    Gets the current date and time.

    Unzip

    Unzip a file to a target directory.

    Version

    Increments a four-part version number stored in a text file

    VssAdd*

    Adds files to a Visual SourceSafe database.

    VssCheckin*

    Checks in files to a Visual SourceSafe database.

    VssCheckout*

    Checks out files from a Visual SourceSafe database.

    VssClean*

    Removes VSS binding information and status files from a solution tree.

    VssDiff*

    Generates a diff between two versions of an item in a Visual SourceSafe database.

    VssGet*

    Gets the latest version of a file or project from a Visual SourceSafe database.

    VssHistory*

    Generates an XML file containing the history of an item in a VSS database.

    VssLabel*

    Labels an item in a Visual SourceSafe database.

    VssUndoCheckout*

    Cancels a checkout of an item from a Visual SourceSafe database.

    WebDirectoryCreate*

    Creates a new web directory on a local or remote machine.

    WebDirectoryDelete*

    Deletes a web directory on a local or remote machine

    WebDownload*

    Downloads a resource with the specified URI to a local file.

    XmlRead

    Reads a value from a XML document using a XPath.

    XmlWrite

    Updates a XML document using a XPath.

    Xslt*

    Merge and transform a set of xml files.

    Zip

    Create a zip file with the files specified.

     * Items not complete or have not been released.

    Sayed Ibrahim Hashimi

    msbuild | Visual Studio Thursday, March 30, 2006 4:21:48 AM (GMT Daylight Time, UTC+01:00)  #     |
    Saturday, March 18, 2006

    Microsoft SDC Tasks

    One of the Microsoft teams based in the UK has created a library of MSBuild tasks that is available for you to download at: http://www.codeplex.com/sdctasks You can download binary versions as well as all the source code for these tasks. There is almost 170 tasks that they have made available! Below is a list of them all if you are interested in what they are.



    ActiveDirectory.Group.AddUser SourceDepot.ReverseIntegrate
    ActiveDirectory.Group.Create SourceDepot.Sync
    ActiveDirectory.User.Create SourceSafe.Get
    ActiveDirectory.User.GrantPrivilege SourceSafe.LabelGet
    AssignCulture SourceSafe.LabelLatest
    BizTalk2002.Configure SourceSafe.Changes
    Cab.AddFile Sql.DisconnectUsers
    Cab.Create Sql.Execute
    Cab.ExtractFile Sql.Access.Revoke
    Certificates.AddCertificate Sql.Role.AddUser
    CheckComponentInstalled Sql.Access.Grant
    CheckProductInstalled ShortenPath"/>
    CodeCoverage.AddAssembly StringToItemList"/>
    CodeCoverage.Create StringComparison"/>
    CodeCoverage.MergeReports StringReplace"/>
    CodeCoverage.Start Summary.AddToReport
    CodeCoverage.Stop Time.Get
    CompileTestSummary Time.Diff
    ComponentServices.Application.AddComponent Time.Report
    ComponentServices.Application.Delete Tools.DevEnv
    ComponentServices.Application.RemoveComponent Tools.FxCop
    ComponentServices.Application.Shutdown Tools.Installshield
    ComponentServices.Application.Update Tools.MsTest"/>
    ComponentServices.Component.Update Tools.Ndoc
    ConsoleReadLine Tools.Nunit
    CreateGuid Tools.PreSharp
    Email Tools.PsExec
    EventSource.Create Tools.StrongName.AddSkipVerification
    EventSource.Log Tools.StrongName.ReSign
    File.Delete Tools.StyleCop
    File.GetFiles TrimJavascript
    File.RegEx VersionNumber.CreateSourceFiles
    Folder.Copy VersionNumber.Load
    Folder.GetInfo VersionNumber.SplitBuildNumber
    Folder.Share.Connect VersionNumber.Update
    Folder.Share.Create VersionNumber.VSSUpdate
    Folder.Share.Delete VirtualServer.VirtualMachine.OS.CheckHeartBeat
    Folder.Share.Disconnect VirtualServer.VirtualMachine.OS.Shutdown
    Folder.Share.Exists VirtualServer.VirtualMachine.Start
    GetInstalledComponents VirtualServer.VirtualMachine.Stop
    GetInstalledProducts Web.AppPool.Create
    GetMetadataValueFromList Web.AppPool.Delete
    GlobalAssemblyCache.AddAssembly Web.FtpSite.Create
    GlobalAssemblyCache.RemoveAssembly Web.FtpSite.CreateVirtualDirectory
    Help.Compile Web.FtpSite.Delete
    Help.CreateProject Web.FtpSite.DeleteVirtualDirectory
    Help.Decompile Web.FtpSite.Start
    Help.DocumentExceptions Web.FtpSite.Stop
    Help.InsertAfter Web.ServiceExtension.AddFile
    Help.InsertBefore Web.ServiceExtension.DeleteFile
    Help.InsertParent Web.WebSite.AddBinding
    LogicalComparison Web.WebSite.AddFilter
    MessageQueue.Create Web.WebSite.AddHttpCustomHeader
    MessageQueue.Delete Web.WebSite.AddMimeType
    MessageQueue.SetPermissions Web.WebSite.Continue
    Msi.EmbedInstallProperties Web.WebSite.Create
    Msi.EmbedUninstallProperties Web.WebSite.CreateVirtualDirectory
    Msi.GetProperty Web.WebSite.Delete
    Msi.Install Web.WebSite.Modify
    Msi.Repair Web.WebSite.DeleteFilter
    Msi.Uninstall Web.WebSite.DeleteVirtualDirectory
    PerformanceCounters.Add Web.WebSite.FilterExists
    PerformanceCounters.Remove Web.WebSite.Pause
    Registry.CreateKey Web.WebSite.Start
    Registry.DeleteKey Web.WebSite.Stop
    Registry.DeleteKeyTree Web.WebSite.UnloadVirtualDirectory
    Registry.Get Web.WebSite.UpdateHttpErrorSetting
    Registry.Set Web.WebSite.UpdateLogSettings
    Security.AddAcl Web.WebSite.UpdateServerCertificate
    Security.RemoveAcl Web.Smtp.Create
    ServiceProcess.Exists Web.Smtp.Start
    ServiceProcess.Start Web.Smtp.Stop
    ServiceProcess.Stop Wix.CompileMsi
    ServiceProcess.UpdateIdentity Wix.LinkMsi
    Sleep Wix.Fragment
    SourceDepot.Changes Xml.CanonicalizeFile
    SourceDepot.ChangesInInterval Xml.ModifyFile
    SourceDepot.CreateBranch Xml.GetValue
    SourceDepot.CreateClientFromTemplate Xml.XslTransform
    SourceDepot.DeleteBranch Zip.AddFile
    SourceDepot.GetChangelistFromDateTime Zip.Create
    SourceDepot.GetChangelistFromLabel Zip.ExtractFile
    SourceDepot.GetUsersForChangelists MergeByOrder
    SourceDepot.Integrate MergeByRef
    SourceDepot.LabelSync



    I’m sure that some of these tasks you’ll find completely useless. For example I presume that most of you will not be needing the SourceDepot.* tasks. But there are several very cool tasks that are made available here. Tasks for code coverage, tasks for invoking common tools and other things. I think its great that they have made this available and hope to see some of these tasks integrated into the next realease of MSBuild.

    Sayed Ibrahim Hashimi


    (Edit: Updated SDC tasks link)

    msbuild | Visual Studio Saturday, March 18, 2006 7:23:16 AM (GMT Standard Time, UTC+00:00)  #     |
    Monday, March 06, 2006

    Removing MS Betas

    A friend of mine was installing SQL Server 2005 & Visual Studio 2005 on a new machine he received. After installing SQL Server 2005, he tried to install VS 2005 and received an error stating that he couldn't install VS 2005 becase beta versions were present on his machine. I had this problem earlier when I needed to upgrade my machine from RC to RTM. The problem was that he accidently installed SQL Server 2005 CTP. I told him to run the him to download and run the Visual Studio Beta Removal tool. When I had this problem it solved it right up for me. Unfortunately, I think Windows got confused with all the installing/un-installing that was going on. He got his machine to the point where SQL Server wouldn't show up in the add/remove programs list, he couldn't run the un-installer for it because it wasn't present, and he couldn't re-install the same CTP version to uninstall it correctly. And of course he couldn't install VS 2005. It seemed like he was in a real tough spot, we searched around for more information about how to get around this situation. I found a tool, the Windows Installer Clean Up tool, that can be used to removal applications and installer files from failed apps that don't show up in the add/remove programs list. When he ran this tool he was able to see and remove the SQL related components. Following this he was able to install the correct versions of SQL Server 2005 & Visual Studio 2005.

    Sayed Ibrahim Hashimi

    Visual Studio | SQL Server 2005 Monday, March 06, 2006 4:57:24 AM (GMT Standard Time, UTC+00:00)  #     |
    Tuesday, February 28, 2006

    MSBuild location of current project file

    When using MSBuild you can import external declarations into your project by using the Import element. This is very useful for distributing your shared targets across your organization, and is a way to segregate where things are located. When MSBuild encounters this tag, a few things happen. First the current directory is changed to that of the file that is being imported. This is done so assembly locations specified by the Using Task and other imports are resolved correctly. What you may be surprised to find out is that if the importing project file declares any items, those item declarations are always relative to the top project file location. To clarify this if you have the following directory structure:

    C:.

    ├───one

       └───Two

               YourProject.proj

    ├───Shared

          CurrentDirectory.dll

          SharedTargets.targets



       └───Another

               SharedTargets_2.targets

    └───utils

            CommandLine.txt

    In this scenario YourProject.proj is the top project file, it imports both SharedTargets.targets and SharedTargets_2.targets files. If the SharedTargets.targets had an item declaration of

    <ItemGroup>
        <Test Include="test.txt"/>
    </ItemGroup>

    When imported by YourProject.proj this item declaration would actually resolve to C:\one\two\test.txt instead of the expected C:\Shared\test.txt value. In 95% of the time this is not an issue at all. But for that other 5% how can we accomplish this?

    Well, there is no magic reserved MSBuild property for this. So we're gonna have to do some work here. To accomplish this we'll have to create a custom MSBuild task. If you've never created an MSBuild task you might be surprised how easy it is!

    I created a new project named DirectoryTask which will house this task. Following this I added a reference to Microsoft.Build.Framework and Microsoft.Build.Utilities assemblies. Following this I wrote the task. It is shown below

    using System;

    using System.Collections.Generic;

    using System.Text;

    using Microsoft.Build.Framework;

    using Microsoft.Build.Utilities;

    namespace CurrentDirectory

    {

        /// <summary>

        /// Task that will return the folder that contains the current project.

        /// Inheriting from AppDomainIsolatedTask causes this task to execute in its own

        /// App domain. Not necessary here, only for demonstration.

        ///

        /// Sayed Ibrahim Hashimi

        /// www.sedodream.com

        /// </summary>

        public class CurrentDir : AppDomainIsolatedTask

        {

            private ITaskItem currentDir;

            [Output]

            public ITaskItem CurrentDirectory

            {

                get

                {

                    return this.currentDir;

                }

            }

            public override bool Execute()

            {

                System.IO.FileInfo projFile = new System.IO.FileInfo(base.BuildEngine.ProjectFileOfTaskNode);

                this.currentDir = new TaskItem(projFile.Directory.FullName);



                return true;

            }

        }

    }

    As you can see this is a pretty simple task. When Execute is called the directory is gathered from the project file that contains the task invocation. The name of the assembly that I built this into is CurrentDirectory.dll.

    Now to see this in action I will use the same directory structure shown above. The contents of the SharedTargets.targets file is:

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">



      <UsingTask AssemblyFile="CurrentDirectory.dll" TaskName="CurrentDir"/>



      <Target Name="SharedTarget">

        <CurrentDir>

          <Output ItemName="CurrentDir" TaskParameter="CurrentDirectory" />

        </CurrentDir>





        <Message Text="Inside the SharedTargets.targets" Importance="high"/>

        <Message Text="Location: @(CurrentDir->'%(Fullpath)')"/>

      </Target>



    </Project>

    This uses the CurrentDirectory task to determine what the current directory is. The SharedTargets_2.targets file is very similar and is:

    <Project xmlns="http://schemas.microsoft.com/developer/msbuild/2003">



      <Target Name="SharedTarget2">



        <
